Circutor Line-CVM-D32 Instruction Manual page 73

line-CVM-D32
Table 15 (Continued): Modbus Memory Map: Measurement variables (Table 1)�
Parameter
Total Capacitive Reactive Power Consumed
Generated Capacitive Reactive Power L1
Generated Capacitive Reactive Power L2
Generated Capacitive Reactive Power L3
Total Capacitive Reactive Power Generated
Consumed Power Factor L1
Consumed Power Factor L2
Consumed Power Factor L3
Three-phase Power Factor consumed
Generated Power Factor L1
Generated Power Factor L2
Generated Power Factor L3
Three-phase Power Factor generated
Cos φ Power consumed L1
Cos φ Power consumed L2
Cos φ Power consumed L3
Cos φ Three-phase Power consumed
Cos φ Power generated L1
Cos φ Power generated L2
Cos φ Power generated L3
Cos φ Three-phase Power generated
Parameter
Voltage phase L1
Current L1
Active Power L1
Inductive reactive power L1
Capacitive reactive power L1
Apparent Power L1
Power factor L1
Cos φ L1
Voltage phase L2
Current L2
Active Power L2
Inductive reactive power L2
Capacitive reactive power L2
Apparent Power L2
Power factor L2
Cos φ L2
Voltage phase L3
Instruction Manual
Instantaneous Value
Table 16: Modbus Memory Map: Measurement Variables (Table 2)�
Maximum Value
Format
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Format Address
Float [32] A0-A1
Float [32] A2-A3
Float [32] A4-A5
Float [32] A6-A7
Float [32] A8-A9
Float [32] AA-AB
Float [32] AC-AD
Float [32] AE-AF
Float [32] B0-B1
Float [32] B2-B3
Float [32] B4-B5
Float [32] B6-B7
Float [32] B8-B9
Float [32] BA-BB
Float [32] BC-BD
Float [32] BE - BF
Float [32] C0-C1
Float [32] C2-C3
Float [32] C4-C5
Float [32] C6-C7
Float [32] C8-C9
Value
Address Units Format
100-101 V Uint [32]
104-105 A Uint [32]
108-109 W Uint [32]
10C-10D varL Uint [32]
110-111 varC Uint [32]
114-115 VA Uint [32]
118-119 - Uint [32]
11C-11D - Uint [32]
120-121 V Uint [32]
124-125 A Uint [32]
128-129 W Uint [32]
12C-12D varL Uint [32]
130-131 varC Uint [32]
134-135 VA Uint [32]
138-139 - Uint [32]
13C-13D - Uint [32]
140-141 V Uint [32]
Units
varC
varC
varC
varC
varC
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Date
Address Units
(10)
102-103 Epoch
106-107 Epoch
10A-10B Epoch
10E-10F Epoch
112-113 Epoch
116-117 Epoch
11A-11B Epoch
11E-11F Epoch
122-123 Epoch
126-127 Epoch
12A-12B Epoch
12E-12F Epoch
132-133 Epoch
136-137 Epoch
13A-13B Epoch
13E-13F Epoch
142-143 Epoch
