7�3�- MODBUS MEMORY MAP
All MODBUS map addresses are in Hexadecimal.
7�3�1�- MEASUREMENT VARIABLES
The Function 0x04: register readout, is implemented for these variables.
Parameter
Voltage phase L1
Current L1
Active Power L1
Inductive reactive power L1
Capacitive reactive power L1
Apparent Power L1
Power factor L1
Cos φ L1
Voltage phase L2
Current L2
Active Power L2
Inductive reactive power L2
Capacitive reactive power L2
Apparent Power L2
Power factor L2
Cos φ L2
Voltage phase L3
Current L3
Active Power L3
Inductive reactive power L3
Capacitive reactive power L3
Apparent Power L3
Power factor L3
Cosφ L3
Frequency
Voltage L1-L2
Voltage L2-L3
Voltage L3-L1
Average phase-phase voltage
Average phase-neutral voltage
Average current
Total Active Power
Total inductive reactive power
Total capacitive reactive power
Total apparent power
Instruction Manual
Table 15: Modbus Memory Map: Measurement variables (Table 1)�
Instantaneous Value
Format Address
Float [32] 00-01
Float [32] 02-03
Float [32] 04-05
Float [32] 06-07
Float [32] 08-09
Float [32] 0A-0B
Float [32] 0C-0D
Float [32] 0E-0F
Float [32] 10-11
Float [32] 12-13
Float [32] 14-15
Float [32] 16-17
Float [32] 18-19
Float [32] 1A-1B
Float [32] 1C-1D
Float [32] 1E-1F
Float [32] 20-21
Float [32] 22-23
Float [32] 24-25
Float [32] 26-27
Float [32] 28-29
Float [32] 2A-2B
Float [32] 2C-2D
Float [32] 2E-2F
Float [32] 34-35
Float [32] 36-37
Float [32] 38-39
Float [32] 3A-3B
Float [32] 3C-3D
Float [32] 3E-3F
Float [32] 40-41
Float [32] 42-43
Float [32] 44-45
Float [32] 46-47
Float [32] 48-49
Units
V
A
W
varL
varC
VA
-
-
V
A
W
varL
varC
VA
-
-
V
A
W
varL
varC
VA
-
-
Hz
V
V
V
V
V
A
W
varL
varC
VA
