line-CVM-D32
7�3�9�- DIGITAL OUTPUTS
Function 0x02 is used for these variables.
Parameter
Digital Output 1 status
Digital Output 2 status
Function 0x04 is used for these variables.
Digital Output 1 alarm activation date
Digital Output 2 alarm activation date
7�3�10�- DEVICE CONFIGURATION VARIABLES
The following functions are used for these variables:
Function 0x03: register readout.
Function 0x10: Writing multiple registers.
7�3�10�1�- Measurement Configuration
Configuration variable
Primary voltage
Secondary voltage
Primary current
Secondary current
Quadrants
Measurement convention
Installation type
Aggregation period (13)
Maximum demand integration
period
Maximum demand calculation
(14)
type
Currency
Display backlight
Password
Current tariff (14)
Harmonics display (15)
(13) The programmed value must be divisible by 60, i.e. the 3660 / Aggregation period division must be exact. It must also
Instruction Manual
Table 27: Modbus Memory Map: Digital output status�
Format
bool
bool
Table 28: Modbus Memory Map: Alarms�
Parameter
Table 29: Modbus Memory Map: Measurement configuration�
Measurement configuration
Format Address
Float [32] 2710-2711
Float [32] 2712-2713
Float [32] 2714-2715
Float [32] 2716-2717
Uint [16] 2722
Uint [16] 1388
Uint [16] 2A9D
Uint [16] 2ACB
Uint [16] 274C
Uint [16] 274D
String 27FC-27FD
Uint [16] 280D
Uint [32] 2A97-2A98
Uint [16] 59DC
Bool 1782
Address Value
0: Deactivated
7539
1: Activated
0: Deactivated
754D
1: Activated
Format Address
Uint [32] 7537-7538
Uint [32] 754B-754C
Valid data range
1.0 ... 2000000.0 V
1.0 ... 2000000.0 V
1.0 ... 2000000.0 A
0.25 ... 5.00 A
2: 2Q - 4: 4Q
0: IEC - 1: IEEE - 2: Circutor
0: 2W-1Ph - 1: 2W-2Ph -
2: 3W-2Ph - 3: 3W-3Ph -
4: 4W-3Ph - 5: ARON
60... 3600 s
60... 3600 s
0: Sliding window
1:Fixed
1... 99 min
00000... 99999
1: Tariff 1 - 2: Tariff 2 -
3: Tariff 3 - 4: Tariff 4
0: Not displayed
FF00: Display
Units
Seconds
Seconds
Default value
-
-
-
-
4
0
4
600 s
900 s
0
EUR
15 min
97531
1
0
91
