line-CVM-D32
Use keys and to skip through the different options:
8N1, no parity, 8 data bits, 1 stop bit
8O2, odd parity, 8 data bits, 2 stop bits
8E2, even parity, 8 data bits, 2 stop bits
8N2, no parity, 8 data bits, 2 stop bit
8O1, odd parity, 8 data bits, 1 stop bit
8E1, even parity, 8 data bits, 1 stop bit
To validate the option, hold down key
Hold down key to configure parameter display refresh time via modbus
Use keys and to skip through the different options:
200 ms,
3 s,
User: x min, value set in the aggregation period parameter, ("
Hold down key to validate the value.
Use key to skip to the next programming point.
6�5�- RATIO CONFIGURATION
6�5�1�- CO EMISSIONS IN CONSUMPTION, TARIFFS 1 AND 2
2
This screen enables carbon emission ratio configuration in consumption.
Carbon emission ratio is the amount of carbon released into the atmosphere to produce one unit of
electricity (1 kWh).
The European mix ratio is approximately 0.65 kgCO
Hold down key to set the emission ratio for Tariff 1 in consumption
Hold down key to set the emission ratio for Tariff 2 in consumption
Use keys and to modify the digit's value.
Press key to skip through the digits.
Hold down key to validate the value.
Instruction Manual
.
per kWh.
2
RATIO T1+
0.00000
RATIO T2+
0.00000
kgCO2
SETUP
(MEASURE TIME)
6.1.5.- CALCULATION PERIODS
(RATIO T1+).
(RATIO T2+).
.
").
55
