Parameter
Current L3
Active Power L3
Inductive reactive power L3
Capacitive reactive power L3
Apparent Power L3
Power factor L3
Cos φ L3
Frequency
Voltage L1-L2
Voltage L2-L3
Voltage L3-L1
Average phase-phase voltage
Average phase-neutral voltage
Average current
Total Active Power
Total inductive reactive power
Total capacitive reactive power
Total apparent power
Three-phase power factor
Cos φ three-phase
THD % voltage L1
THD % voltage L2
THD % voltage L3
THD % Current L1
THD % Current L2
THD % Current L3
Reactive Power L1
Reactive Power L2
Reactive Power L3
Total Reactive Power
Consumed Reactive Power L1
Consumed Reactive Power L2
Consumed Reactive Power L3
Total consumed reactive power
Generated Reactive Power L1
Generated Reactive Power L2
Generated Reactive Power L3
Total generated reactive power
Consumed Active Power L1
Consumed Active Power L2
Consumed Active Power L3
Total Active Power Consumed
74
Table 16 (Continued): Modbus Memory Map: Measurement variables (Table 2)�
Maximum Value
Format
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Float [32]
Value
Address Units Format
144-145 A Uint [32]
148-149 W Uint [32]
14C-14D varL Uint [32]
150-151 varC Uint [32]
154-155 VA Uint [32]
158-159 - Uint [32]
15C-15D - Uint [32]
168-169 Hz Uint [32]
16C-16D V Uint [32]
170-171 V Uint [32]
174-175 V Uint [32]
178-179 V Uint [32]
17C-17D V Uint [32]
180-181 A Uint [32]
184-185 W Uint [32]
188-189 varL Uint [32]
18C-18D varC Uint [32]
190-191 VA Uint [32]
194-195 - Uint [32]
198-199 - Uint [32]
19C-19D % Uint [32]
1A0-1A1 % Uint [32]
1A4-1A5 % Uint [32]
1AC-1AD % Uint [32]
1B0-1B1 % Uint [32]
1B4-1B5 % Uint [32]
1BC-1BD var Uint [32]
1C0-1C1 var Uint [32]
1C4-1C5 var Uint [32]
1C8-1C9 var Uint [32]
1CC-1CD var Uint [32]
1D0-1D1 var Uint [32]
1D4-1D5 var Uint [32]
1D8-1D9 var Uint [32]
1DC-1DD var Uint [32]
1E0-1E1 var Uint [32]
1E4-1E5 var Uint [32]
1E8-1E9 var Uint [32]
1EC-1ED W Uint [32]
1F0-1F1 W Uint [32]
1F4-1F5 W Uint [32]
1F8-1F9 W Uint [32]
line-CVM-D32
Date
Address Units
(10)
146-147 Epoch
14A-14B Epoch
14E-14F Epoch
152-153 Epoch
156-157 Epoch
15A-15B Epoch
15E-15F Epoch
16A-16B Epoch
16E-16F Epoch
172-173 Epoch
176-177 Epoch
17A-17B Epoch
17E-17F Epoch
182-183 Epoch
186-187 Epoch
18A-18B Epoch
18E-18F Epoch
192-193 Epoch
196-197 Epoch
19A-19B Epoch
19E-19F Epoch
1A2-1A3 Epoch
1A6-1A7 Epoch
1AE-1AF Epoch
1B2-1B3 Epoch
1B6-1B6 Epoch
1BE-1BF Epoch
1C2-1C3 Epoch
1C6-1C7 Epoch
1CA-1CB Epoch
1CE-1CF Epoch
1D2-1D3 Epoch
1D6-1D7 Epoch
1DA-1DB Epoch
1DE-1DF Epoch
1E2-1E3 Epoch
1E6-1E7 Epoch
1EA-1EB Epoch
1EE-1EF Epoch
1F2-1F3 Epoch
1F6-1F7 Epoch
1FA-1FB Epoch
