4�5�- DIGITAL OUTPUTS
The device has two digital transistor outputs (terminals 19, 20 and 21 in
). The digital outputs
Table 4
can be configured as alarms, pulse outputs or can be manually activated via the configuration menu,
see
"6.6.- CONFIGURATION OF DIGITAL OUTPUTS 1 and 2".
21
19
C
Carga
Load
Fuente externa
External load
2
1
Salidas de transistor
Transistor outputs
Figure 25: Digital transistor outputs�
29
Instruction Manual
