line-CVM-D32
Use keys and to modify the digit's value.
Press key to skip through the digits.
Hold down key to validate the value.
 Tariff 1 and 2 ratio per kWh in consumption:
Minimum value: 0.00000 EUR
Maximum value: 99.99999 EUR
Use key to skip to the next programming point.
6�5�4�- ENERGY COST IN CONSUMPTION, TARIFFS 3 AND 4
This screen enables configuration of the costs per kWh of electricity for tariffs 3 and 4 in consumption.
to set the ratio per kWh for Tariff 3 in consumption
Hold down key
to set the ratio per kWh for Tariff 4 in consumption
Hold down key
Use keys and to modify the digit's value.
Press key to skip through the digits.
Hold down key to validate the value.
 Tariff 3 and 4 ratio per kWh in consumption:
Minimum value: 0.00000 EUR
Maximum value: 99.99999 EUR
Use key to skip to the next programming point.
6�5�5�- CO EMISSIONS IN GENERATION, TARIFFS 1 AND 2
2
Note: Display visible if the device has been configured to operate in all 4 quadrants
RANTS AND MEASUREMENT CONVENTION")
This screen enables carbon emission ratio configuration in generation.
Carbon emission ratio is the amount of carbon released into the atmosphere to produce one unit of
electricity (1 kWh).
The European mix ratio is approximately 0.65 kgCO
Instruction Manual
RATIO T3+
0.00000
RATIO T4+
0.00000
EUR
SETUP
per kWh.
2
(RATIO T3+)
(RATIO T4+).
("6.1.3.- QUAD-
57
