CVM-NET4+-MC
Modbus Address
089B
089C
089D
089E
089F
08A0
08A1
08A2
08A3
Example of a write command. Deleting Channel 3 three-phase energies.
TX: NP 05 0846 FF00 CRC
RX: NP 08 0846 FF00 CRC
4�4�8�- CONFIGURATION AND USE OF DIGITAL OUTPUTS
4�4�8�1�- Forcing digital outputs
The device features four digital outputs that can be remotely managed in both their opening and clos-
ing functions.
Table 13:Configuration and use of digital outputs, forcing digital outputs
Use of Digital Outputs
Modbus Address
Example of forcing Digital Output number 1:
TX: NP 05 000F FF 00 CRC
RX: NP 05 000F FF 00 CRC
4�4�8�2�- Reading the digital output status
The user can request a reading of the digital output status via Modbus/RTU using the following sen-
tence:
TX: NP 04 4E21 0001 CRC
RX: NP 04 04 02 000 CRC
Bit 8
Bit 7
-
-
Instruction Manual
Table 12 (Cont�): Deleting energies
Deleting Channel 2- 1S1 Single phase Energies
Deleting Channel 2- 2S1 Single phase Energies
Deleting Channel 2- 3S1 Single phase Energies
Deleting Channel 3- 1S1 Single phase Energies
Deleting Channel 3- 2S1 Single phase Energies
Deleting Channel 3- 3S1 Single phase Energies
Deleting Channel 4- 1S1 Single phase Energies
Deleting Channel 4- 2S1 Single phase Energies
Deleting Channel 4- 3S1 Single phase Energies
Output
000F
Output 1
0010
Output 2
0011
Output 3
0012
Output 4
Converting to Binary - 1 Byte (0 = Open / 1 = Closed)
Bit 6
Bit 5
-
-
Variable
Open / Close
00 / FF
00 / FF
00 / FF
00 / FF
Bit 4
Bit 3
Out 4
Out 3
Data margin
FF
FF
FF
FF
FF
FF
FF
FF
FF
Bit 2
Bit 1
Out 2
Out 1
17
