GE MAC 1200 Operator's Manual page 141

Creating a New Protocol
Resetting the Protocol
Printing the Protocol
Saving the Protocol (OK)
Quitting the Protocol Editor
Revision C
System Setup: Stress Test Mode
1. Position the cursor on [new proto.] and push
showing 3 command buttons and a list of all existing protocols.
2. Select a protocol (in the figure on the next page, protocol 4 STD
FRANCE is selected) and confirm with
3. Position the cursor on [new proto.] and confirm with
You will see the Protocol Editor with the parameters for STD FRANCE.
Question marks appear in place of the protocol name. You can overwrite
them with a name of your choice. The test parameters can be edited as
needed.
With the reset proto. command, you can restore all parameters to the
values that were active when you first called up the protocol editor.
Initiates a printout of the displayed protocol.
With OK, you save the displayed protocol.
With the Escape command, you quit the Protocol Editor. Changes to the
parameter values will be ignored and are not saved.
MAC 1200/1200 ST
2012250-021
. A screen appears
.
.
10-17
