3.3.9

USB

Feature
USB Module version
USB Devices:
Legacy USB Support
XHCI Hand-off
EHCI Hand-off
USB Mass Storage Driver Support
USB Configuration
USB transfer time-out
Device reset time-out
Device power-up delay
3.3.10 F81216 Second Super IO
Feature
I81216 Super IO Configuration
Serial Port 0 Configuration
Serial Port 1 Configuration
Serial Port 2 Configuration
Serial Port 3 Configuration
F81216 Second Super IO > Serial Port 0-3 Configuration
Feature
Serial Port 0 Configuration
Serial Port
Device Setting
Change Setting
RS232/RS422
BIOS Setup
Options Description
Info only
Info only
Enables Legacy USB support.
Enabled
Disabled
This is a workaround for OSes without XHCI
Enabled
Disabled hand-off support.
Enabled This is a workaround for OSes without EHCI
hand-off support.
Disabled
Enable/Disable USB Mass Storage Driver
Enabled
Disabled Support.
PCH USB Configuration
1 sec The time-out value for Control, Bulk, and Interrupt
5 sec transfers.
10 sec
20 sec
10 sec USB mass storage device start unit command
time-out.
20 sec
30 sec
40 sec
Maximum time the device will take before it
Auto
Manual properly reports itself to the host controller.
Options Description
Info only
Submenu Set Parameters of Serial Port 0.
Submenu Set Parameters of Serial Port 1.
Submenu Set Parameters of Serial Port 2.
Submenu Set Parameters of Serial Port 3.
Options Description
Info only
Disabled Enable or Disable Serial Port (COM)
Enabled
Info only
Auto
IO=260;IRQ=11;
IO=260;IRQ=10,11,12
IO=268;IRQ=10,11,12
IO=270;IRQ=10,11,12
IO=278;IRQ=10,11,12
RS232
RS422
Select an optimal settings for Super IO
Device.
RS232/RS422 selection
