HPERC-IBR-M Setup

1.1 About the HPERC-IBR-M

The HPERC products are intended for users of embedded systems requiring long life-cycles,
configuration control, and ruggedness in hardened military packages. HPERC models feature
Extreme Rugged™ computer boards available with varieties of processors and memory. An
optional operating system (OS) can be pre-loaded onto an optional internal storage device (two
2 ½" Solid State Drives (SSDs). Board Support Packages (BSPs) are provided on the optional
Support Software QuickDrive™ to support additional OSs. Just use a USB memory to load your
application software and you are ready to use your system.

1.2 Using this Guide

This guide provides the most efficient way to set up your HPERC-IBR-M with your desired OS.
The instructions provided in this guide include:
Removing the HPERC-IBR-M from the shipping container and inspecting the accesso-
ries
Connecting peripherals to the HPERC-IBR-M
Powering up the HPERC-IBR-M
Information not provided in this User's Guide includes:
Board or Module specifications
Board or Module header signals and descriptions
Operating system programming or operating instructions
NOTE: Refer to OS manufacturers' manuals for instructions when using OS software.

1.3 Requirements

The following peripherals and devices are needed to make full use of the HPERC-IBR-M.
Peripherals (user-provided):
USB or PS/2 keyboard
USB or PS/2 mouse
Display monitor
NOTE: The items listed above are not available from ADLINK.
Power Supply (optional):
AC Adapter (with plug-type mating cord)

1.4 Device/Peripheral Connections

Ethernet (LAN) connections
USB device connections
At least one PCI/104-Express expansion module
