Serial Port Console > Console Redirection Settings
Feature
COM0
Console Redirection Settings
Terminal Type
Bits per second
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Putty Keypad
Redirection After BIOS Post
34
Options Description
Info only
VT100 VT100: ASCII char set.
VT100+: Extends VT100 to support color,
VT100+
VT-UTF8 function keys, etc. VT-UTF8: Uses UTF8
ANSI encoding to map Unicode chars onto 1 or more
bytes.
ANSI: Extended ASCII char set.
9600 Selects serial port transmission speed. The
19200 speed must be matched on the remote computer.
38400 Long or noisy lines may require lower speeds.
57600
115200
7 Select data bits.
8
Select parity.
None
Even
Odd
Mark
Space
1 Select number of stop bits.
2
Select flow control.
None
Hardware RTS/CTS
Disabled Enable VT-UTF8 combination key support for
ANSI/VT100 terminals.
Enable
With this mode enabled only text will be sent.
Disabled
Enable This is to capture terminal data.
Enables or disables extended terminal resolution
Disabled
Enable
On legacy OSes, the number of rows and
80x24
80x25 columns supported by redirection
Select Function Key and Keypad on Putty.
VT100
LINUX
XTERMR6
SCO
ESCN
VT400
The Settings specify if BootLoader is selected,
Always Enabled
BootLoader then legacy console redirection is disabled before
booting to legacy OS.
BIOS Setup
