ADLINK Technology HPERC-IBR-MC User Manual page 48

System Agent Configuration > Graphics Configuration > LCD Control
Feature
Primary IGFX Boot Display
DDI Function choose
Spread Spectrum clock Chip
System Agent Configuration > NB PCIE Configuration
Feature
PEG0
PEG0 – Gen X
System Agent Configuration > Memory Configuration
Feature
Memory RC Version
Memory Frequency
Total Memory
Memory Slot0
Memory Slot1
CAS Latency (tCL)
CAS to RAS (tRCDmin)
Row Precharge (tRPmin)
Active to Precharge (tRASmin)
38
Options Description
Vbios Default Select the Video Device which will be activated
during POST.
CRT
EFP
LFP
EFP3
EFP2
LFP2
Display Port DDI function choose to Display Port or HDMI.
HDMI
>>Hardware: Spread is controlled by chip;
Off
Hardware >>Software: Spread is controlled by BIOS.
Software
Options Description
Info only
Configure PEG0 B0:D1:F0 Gen1-Gen3.
Auto
Gen1
Gen2
Gen3
Options Description
Info only Display memory RC Version
Info only Display memory frequency
Info only Display total system memory size
Info only Display Slot 0 memory size
Info only Display Slot 1 memory size
Info only Memory Timing
Info only Memory Timing
Info only Memory Timing
Info only Memory Timing
BIOS Setup
