ADLINK Technology HPERC-IBR-MC User Manual page 13

Operating Temperature
Storage Temperature
Power
Relative Humidity
Immersion
Shock
Vibration
EMC Compliance
HPERC-IBR-M Setup
MC:
• Baseplate Point Extreme Rugged
• -40°C to +85°C (i7-3517UE)
• -40°C to +80°C (i7-3612QE)
• Coldplate conduction
• VITA 75.22 mount
MH:
• Ambient:40°C to +70°C at 1 atm air
• Heatsink (free air convection)
• VITA 75.21 mount
-55°C to 85°C
Input: +10 to +36VDC input
Performance:
• P-State 0-16 (Speedstep & Turbo)
• S-State: S3, S4
95% at +60°C non-condensing
IEC60529 Edition 2.2: 2013; IP67
MIL-STD-810G, 516.6 Procedure I (Functional Shock)
• Table 516.6-I (40 G for Ground Equipment)
MIL-STD-810G, 516.6 Procedure V (Crash Hazard)
• Table 516.6-I (75 G for Crash Hazard Shock)
MIL-STD-810G, Table 514.6C-X. Category 9- Helicopter vibration exposure
(General)
MIL-STD-810G, Figure 514.6C-10 Category 11 - Rail cargo vibration
exposure.
MIL-STD-810G, Figure 514.6D-9. Category 21 -Shipboard random vibration
exposure
MIL-STD-810G Table 514.6C-VI Category 4- Composite wheeled vehicle
vibration exposure
MIL-STD-461F certification
Test Item Ground Army, Aircraft, Navy compliance
• CE101: Navy ASW aircraft & Army aircraft (incl. flight line, below 28V)
• CE102: Ground Army, Aircraft, Navy
• CS101: Ground Army, Aircraft, Navy
• CS115: Ground Army, Aircraft, Navy
• RE102: Air & space(fixed Wing External and Helicopters)
• RS101: Ground Army
• RS103: 100V/m (Ground Army, Ground Navy)
• RE101: Ground Navy
• CS106: Ground Army, Aircraft, Navy (Vpeak=400V)
• CS114: Aircraft (External or safety critical) -Curve5
• CS116: Ground Army, Aircraft, Navy (Imax=10A)
FCC EN55022 Class A
Table 1-1: HPERC-IBR-M Specifications
HPERC-IBR-M
3
