1.5 Specifications

VITA Standards
Mechanical
Processor
Chipset
Host Memory
BIOS
Graphics
GPGPU
Gigabit Ethernet
Serial Port
USB 2.0
PS/2
GPIO
Audio Port
TPM
Storage Interface
RAID
I/O Connecter
Expansion Busses
OS Compatibility
2
VITA 75
MC:
• Form Factor: VITA-75.22 Conductive Coldplate
• Dimension: 223.38(L) x 177.8(W) x 68.7(H) mm (with mounting brackets)
• Weight: 3.12 kg
MH:
• Form Factor: VITA-75 Finned Passive Convection
• Dimension: 304.8(L) x 150(W) x 101.95(H) mm (with mounting brackets)
• Weight: 3.91 kg
22nm FCBGA Intel® Core™ i7 Processor
• 4-core Intel® Core™ i7-3612QE Processor, 2.1 GHz, 6MB L3 cache,
TDP 35W
• 2-core Intel® Core™ i7-3517UE Processor, 1.7 GHz, 4MB L3 cache,
TDP 17W
Intel® BD82QM77 Platform Controller Hub (PCH)
Dual channel DDR3-1066/1333 SDRAM with ECC, total up to 16GB
One channel in SODIMM sockets up to 8GB
One channel soldered onboard to 8GB
AMI EFI BIOS, 64Mbit SPI flash memory
Integrated in processor
One VGA, two DVI and one HDMI
General-purpose GPU via MXM slot (PCIe x16 Gen3)
• GT745M with 2 GB GDDR5 128-bit RAM
• GTX950M with 2 GB GDDR5 128-bit RAM
Four Intel® I210 10/100/1000BASE-T ports
Seven RS-232/RS-422 serial ports
Six USB 2.0 ports routed
One PS/2 Keyboard port
One PS/2 Mouse port
Eight digital IO
One amplified stereo output
One stereo input
Atmel AT97SC3204-U1A190 TPM
Two SATA 6 Gb/s direct connector for 2.5" onboard drive
SLC/MLC SSD on SATA 6 Gb/s (up to 1 TB)
One removable SDIO socket supports up to 64GB SDHC on panel
Supports RAID 0/1
MIL-DTL-38999 (uniquely-keyed)
MXM (3rd Generation PCIe x16)
PCI/104 Express® Type 2 (PCIe Gen2)
PCI Express Mini Card (PCIe Gen2)
Microsoft Windows 7 64-bit
Microsoft WES7 x86/x64
Wind River VxWorks 6.9.3.1 BSP
Other OS support on request

Table 1-1: HPERC-IBR-M Specifications
