6.9 USB and LAN
CN6:
USB x4 Connector
CN7:
RJ-45 Gbe LAN
+ USB
CN13:
USB Header
Page 22
Pin
1
2
3
4
Pin
1
2
3
4
5
6
7
8
Pin
1
2
3
4
Pin
1
1
2
3
4
Express-BASE User's Manual
Signal
+5V
USB-
USB+
Ground
Signal
MDI[0]+
MDI[0]-
MDI[1]+
MDI[1]-
MDI[2]+
MDI[2]-
MDI[3]+
MDI[3]-
Signal
+5V
USB-
USB+
Ground
Signal
+5V
USB-
USB+
Ground
