1.16.2 P3 Pin Definitions
Table 1-8 Provides the pin definitions and signal maps for the P3 Military Connector.
P3
Interface
Pin
1 VGA
2 Ground
33 Ground
3 VGA
4 VGA
5 Ground
6 VGA
18 Ground
7 VGA
21 Ground
14 VGA
30 Ground
8 VGA
9 Power
10 Power
11 Ground
12 Power
13 Power
15 Power
38 Ground
24 Control/Indicator
99 Ground
114 Control/Indicator
99 Ground
121 Control/Indicator
99 Ground
16 Gigabit Ethernet 4
17 Gigabit Ethernet 4
18 Ground
19 Gigabit Ethernet 4
20 Gigabit Ethernet 4
21 Ground
22 Gigabit Ethernet 4
23 Gigabit Ethernet 4
100 Gigabit Ethernet 4
101 Gigabit Ethernet 4
25 Serial 1
26 Serial 1
27 Serial 1
28 Serial 1
29 NC
18
Signal
VGA_VSYNC
GND
GND
VGA_DDC_SCL
VGA_DDC_SDA
GND
RED
GND
GREEN
GND
BLUE
GND
HSYNC
P3V3_S
P3V3_S
GND
P3V3_S
P3V3_S
P3V3_S
GND
PCIe_ETH_5/5_LED1
GND
PCIe_ETH_4/5_LED1
GND
PCIe_ETH_3/5_LED1
GND
GbE5_MDI0_N
GbE5_MDI0_P
GND
GbE5_MDI1_N
GbE5_MDI1_P
GND
GbE5_MDI2_N
GbE5_MDI2_P
GbE5_MDI3_N
GbE5_MDI3_P
RS422_TX1_N
RS422_TX1_P
RS422_RX1_N
RS422_RX1_P
NA

Table 1-8: P3 Connector Pin Signals

Signal Description
Vertical Sync
Ground
Ground
Display Data Channel - Serial
Clock
Display Data Channel - Serial
Data
Ground
Red Analog Output
Ground
Green Analog Output
Ground
Blue Analog Output
Ground
Horizontal Sync
+3.3 Volts Standby
+3.3 Volts Standby
Ground
+3.3 Volts Standby
+3.3 Volts Standby
+3.3 Volts Standby
Ground
Ethernet LED
Ground
Ethernet LED
Ground
Ethernet LED
Ground
Ethernet4 MDI0 Negative
Ethernet4 MDI0 Positive
Ground
Ethernet4 MDI1 Negative
Ethernet4 MDI1 Positive
Ground
Ethernet4 MDI2 Negative
Ethernet4 MDI2 Positive
Ethernet4 MDI3 Negative
Ethernet4 MDI3 Positive
Transmit Data Negative
Transmit Data Positive
Receive Data Negative
Receive Data Positive
NA
