1.8 Power Specifications (with GPGPU)

Table 1-3 defines the current draw values of the HPERC-IBR-M, 3612QE i7 CPUs. The table
captures Idle, and Burn-In-Test (BIT) currents.
Table 1-3 lists the current draw values of the HPERC-IBR-M
Configuration
CPU: Intel® Core™ i7-3612QE Processor (6M cache, up to 2.10 GHz, Max Turbo Fre-
quency 3.1GHz)
Memory: Micro PC3-10700 DDR3 1600 8G x2 (onboard and slot), total 16GB
Storage: Transcend 256G TS256GSSD370I 2.5" x2 (6GB/S) x2
GPGPU: NVIDIA GeForce GT 745M - X3N745M-FN
Mini PCIe: Innodisk_MiniPCIeDOM_1ME 64G (Gen1)
Input Type
Windows Idle mode
Windows typical mode
(Burn in test 100% loading)
Windows MAX mode
(Intel® Thermal Analysis Tool
100% loading)

1.9 Environmental Specifications

Table 1-4 provides the most efficient operating and storage condition ranges required for this
system.
Operating
HPERC-MC (conduction coo)
-40° to +85°C (Core™ i7-3517UE 17W)
-40° to +80°C (Core™ i7-3612QE 35W)
(temp. of hottest/coldest point on baseplate)
HPERC-MH (air cooled)
-40°C to +70°C at 1 atm air
(required airflow TBD)
6
Parameter

Table 1-3: System Power Requirements (with GPGPU)

Temperature
Storage
–55° to +85°C

Table 1-4: Environmental Requirements

2.1GHz CPU (i7-3612QE)
+24 VDC Regulated DC
24V, 1.27A, 30.48W
ESIT disabled: 24V, 1.33A, 31.92W
24V, 2.50A, 60W
ESIT disabled: 24V, 2.25A, 54W
24V, 2.88A, 69.1W
ESIT disabled: 24V, 2.79A, 66.96W
Operating
5% to 90%
relative humidity,
non-condensing
Humidity
Non-operating
5% to 95%
relative humidity,
non-condensing
