LED Color Status
Green/ Green
Orange
Green
Orange
2.2.5

eSATA connectors

The MXE-3000 provides two SATA ports on the front panel, con-
sisting of integrated AHCI controllers supports SATA interface
HDD, SSD, and CD-ROM devices.
2.2.6

USB 2.0 Connectors

The MXE-3002 controller provides six USB 2.0 Type A ports on
the front and rear panels. All USB ports are compatible with high-
speed, full-speed and low-speed USB devices. The MXE-3002
controller supports multiple boot devices, including USB flash
drive, USB external hard drive, USB floppy, USB CD-ROM and
others. The boot priority and boot device can be configured in
BIOS. Please refer to Section 4.5 for details.
System Description
Description
10 Mbps
100 Mbps
1000 Mbps

Table 2-5: Realtek 8111C Speed LED
