1.17 Applying Power to the HPERC-IBR-M

1) Follow these steps to
apply power to the
HPERC-IBR-M.
2) Verify the HPERC-IBR-M
satisfactorily powers on.
3) Using the
Operating
System (OS)
22
• Connect the AC Mating Cable to the AC Adapter (options.) See
Figure 1-3.
• Plug in the DC Cable Connector from the AC Adapter (option) to
the DC IN jack onthe HPERC-IBR-M. See Figure 1-7.
• +10VDC to +36VDC
• Plug in the VGA or LCD monitor's power cord to an AC outlet
and turn on the monitor.
• Plug in the AC Mating cable to an AC outlet.
• Press the HPERC-IBR-M Power On button on the breakout
cable to power on the HPERC-IBR-M.
• To enter the BIOS Setuppress the <Del> key during power-on
self test (POST).
Use BIOS Setup during the initial boot to set the
desired options.
• You should see POST complete successfully before the system
starts loading the operating system (optional.) If you are using
Linux, the boot loader will appear first, similar to the one shown
below with the corresponding OS name displayed.
(The Linux x.x OS is shown as an example.)
GNU GRUB version 0.xx (xxxk lower/xxxxxx upper memory)
Linux Kernel 2.6.x-xxx (recovery mode)
Use the and keys to select which entry is highlighted.
Press Enter to boot the selected OS, 'e' to edit the
commands before booting, 'a' to modify the kernel
arguments before booting, or 'c' for a command-line.
• You should see a prompt on the monitor screen indicating the OS is loading,
or has loaded.
• Refer to the respective OS manual (not supplied by ADLINK.)
CAUTION: Power supplied to the unit must
be within the allowed range depending on
the model of the unit:
CAUTION: Failure to provide proper power may
damage the system and void the warranty.
HPERC-IBR-M Setup
