Rack Ear Installation Option (P/N: 70-0361-101)
The rackmount installation option includes all the parts necessary to mount an EX1200 system to
the front of a standard test rack.
Required Tools
1) #2 Phillips screwdriver
Parts List
Item#
1
2
Assembly Procedure
1) Place the chassis on a protected work surface with its input connectors facing front.
2) Using a #2 Phillips screwdriver, install the rack ears (P/N: 41-0482-009) on the front of the
EX1200 using five (5) 6-32 x 3/8" flat head Phillips stainless steel screws (P/N: 37-0114-025)
for each rack ear. Note that the "Optional Mounting Locations" in Figure 2-9 allow the
EX1200 to be installed in a rack either flush or recessed.
F
IGURE
46
Qty
Description
2
Rack Ear, EX1200
Screw, 6-32 x ¼", F/H Undercut Phillips, Zinc
10
2-9: R
E
I
ACK
AR
NSTALLATION
D
(E
F
IAGRAM
XPLODED
RONT
EX1200 Series Preparation for Use
VTI P/N
41-0472-008
37-0114-025
