VTI Instruments Corp.
To use ACE, use the following steps:
1) Open ACE and click on the Add instrument toolbar.
2) Select Add LAN instrument on LAN and then click OK. ACE will search the network and
list the LXI instruments connected to the LAN.
3) To simply view the EX1200 web page, click on its webpage button. If desired, the EX1200
can be added to ACE as a LAN instrument by enabling the appropriate Select checkbox and
then clicking OK.
L SFP
OGIN INTO
EX1200 calibration is performed using the SFP web interface. If a password has been created for
the EX1200 mainframe, accessing an action or entry page for the first time during a session will
cause an Error page will appear. To clear this error, click on the login link. The Login page will
appear. In the Password field, enter the configured instrument password. For additional
information, refer to the Web Page Operation discussion in Section 7.
NOTE To reset the password to factory default, click the Change Password link in the left side menu.
146
F 9-5: A I
IGURE DD NSTRUMENT
F 9-6: A
IGURE CCESSING THE
I
NTERFACE
EX1200 V ACE
IA
EX1200 Series Maintenance
