Section 7; Web; Eb Age Peration; Introduction - VTI Instruments Metek EX1202 User Manual

W P O
EB AGE
I
NTRODUCTION
To open the embedded web page, start the LXI Discovery Tool utility by navigating to Start →
Programs → LXI Discovery Tool. Once the utility is run, LXI Discovery Tool will scan the
network to discover all LAN-based VTI instruments. Once the scan is complete, the tool shows all
the instruments that were discovered, as shown in Figure 7-1. To open the web page, click on the
Open Web Page. The IP address of the EX1200 can also be viewed from this window as well as
its firmware version.
F
IGURE
Alternatively, the EX1200 may also be discovered using Internet Explorer's Bonjour for Windows
plug-in. The IP address of the EX1200 can also be entered into the address bar of any web browser
to view the embedded web page. By default, the EX1200 will first attempt to use DHCP to set its
IP Address. If DHCP is not available on the network it is connected to, it will instead use Auto IP.
Determining the Auto IP address is discussed in the Network Configuration discussion in
Section 2. Other discovery methods, such as VXI-11, can be used as well.
EX1200 Series Maintenance
PERATION
7-1: LXI D T
ISCOVERY
S
ECTION
OOL DISPLAYING ALL THE INSTRUMENTS ON THE
N
ETWORK
