Once the standards have been connected, the following connections should be made to the
EX1200:
8) Connect the EX1200 LAN port to the Ethernet switch using an Ethernet cable.
9) Connect the function generator, external DMM, and calibrator to the DMM as shown in
Figure 9-5 using the EX1200 DMM calibration/verification cable (VTI P/N: 52-0807-000).
Output HI
Output LO
Sync HI
Sync LO
Function Generator
NOTE Be certain that the calibrator is in standby mode (i.e. not outputting) before the cables are
connected to eliminate the possibility of having the function generator and calibrator generating
outputs at the same time while shorted together.
C
ONNECTING TO THE
There are three ways to connect to the EX1200: using the IP address of the EX1200, using
Bonjour for auto-discovery, or using the Agilent Connection Expert (ACE). For more information
on obtaining the EX1200's IP address and using this as the connection method, refer to the
Network Configuration discussion in Section 2. To connect to the EX1200 via Bonjour, refer to
Section 7: Web Page Operation.
EX1200 Series Maintenance
LAN/GPIB Gateway
GPIB Port
LAN Port
Ethernet
Cable
Ethernet
Switch
LAN Port
Ethernet
Cable
LAN Port
PC
F 9-4: I
IGURE NSTRUMENT
Input I
Input HI
Input LO
Sense HI
Sense LO
External DMM
F 9-4: EX1200 C
IGURE
EX1200
Calibrator
GPIB
Cable
Interconnect Cable
Amplifier
8.5 Digit DMM
Function Generator
C EX1200 DMM C
ONNECTIVITY FOR
Output I
Output HI
Output LO
Sense HI
Sense LO
Calibrator
R
ONNECTIVITY TO EFERENCE
www.vtiinstruments.com
GPIB Port
GPIB
Cable
Daisy
Chain
GPIB
GPIB Port
Cable
Daisy
Chain
GPIB Port
ALIBRATION
Input I
Input HI
Input LO
Sense HI
Sense LO
EX1200 DMM
S
TANDARDS
145
