ENERAL PECIFICATIONS
M S
ODULE LOTS
1 U Mainframes
EX1202 (EX1262)
EX1206 (EX1266)
3 U Mainframes
EX1208 (EX1268)
D
IMENSIONS
1 U Mainframes
EX1202/EX1262
EX1206/EX1266
3 U Mainframes
EX1208/EX1268
: Add 0.5" to depth for DMM handles.
1
Note
: Add 1.0" to depth for DMM handles.
2
Note
W
EIGHT
1 U Mainframes
EX1202/EX1262
EX1206/EX1266
3 U Mainframes
EX1208/EX1268
E
NVIRONMENTAL
Operating temperature
Operating altitude
Operating humidity
Storage temperature
Storage altitude
Storage humidity
Shock and vibration
P S
OWER PECIFICATIONS
1
A P
VAILABLE OWER
EX1202/06/62/66
EX1208/68
1
U P
SEABLE OWER
EX1202/EX1206
EX1262/EX1266
EX1208/68 (Slots 1 – 5)
EX1208 (Slots 6 – 10)
EX1268 (Slots 6 – 10)
EX1208/68 (Slots 11 – 16)
*The EX12x8 mainframe is powered by four power supplies and each power supply is used for a finite number of mainframe slots. For more
information, see the Power Consumption in Appendix B.
M C P
AXIMUM URRENT ER
EX1202/EX1206
EX1262/EX1266
EX1208/68 (Slots 1 – 5)
EX1208/68 (Slots 6 – 10)
EX1208/68 (Slots 11 – 16)
1
Note : The EX12x8 mainframe is powered by four power supplies and each power supply is used for a finite number of mainframe slots. For
more information, see the Power Consumption in Appendix B.
2
Note : For more information on calculating power consumption, please refer to the Power Consumption in Appendix B.
3
Note : These values indicate the maximum current provided by the power supply. This value is limited by the carrying capacity for that rail. See
the Maximum Current Carrying Capacity per Slot specification for more information.
M C C
AXIMUM URRENT ARRYING
3.3 V rail
5 V rail
24 V rail
I P R
NPUT OWER ATING
EX1262/EX1266
14
EX1200 S
YSTEM
Two standard plug-in module (PIM) slots (plus 6½ digit DMM)
Six standard PIM slots (plus 6½ digit DMM)
Sixteen standard PIM slots (plus 6½ digit DMM)
Embedded, ½ rack U mainframe (17.22" D, 8.61" W, 1.75" H)
Embedded, 1 rack U mainframe (17.22" D
Embedded, 3 rack U mainframe (19.49" D
4.9 lbs (2.3 kg)
7.1 lbs (3.2 kg)
16.2 lbs (7.4 kg)
0 °C – 55 °C
10,000 ft (3,000 m) maximum
5% - 95% non-condensing @ 0°C - 30°C, 5% - 75% non-condensing @ 30 °C – 40 °C,
5% - 45% non-condensing @ 40 °C – 50 °C (per 3.8.2 of MIL-PRF-28800F Class 3)
-40 °C – 70 °C
15,000 ft (4,500 m) maximum
5% – 95%, non-condensing
Per 3.8.5 of MIL-PRF-28800F, Class 3
120 W
120 W per segment, 360 W total
115 W
110 W
102 W
97 W
102 W
102 W
1,2
R 3.3 V
AIL
6.00 A
6.00 A
14.99 A
14.99 A
14.99 A
C P S
APACITY ER LOT
6 A
3.75 A
1.6 A
230 VA
S
PECIFICATIONS
, 17.27" W, 1.75" H)
1
, 16.72" W, 5.22" H)
2
5 V 24 V
13.420 A 3.320 A
13.410 A 3.074 A
13.582 A 2.950 A
13.362 A 2.950 A
13.355 A 2.950 A
