Rackmount Installation, Dual Half Rack Width Option (P/N: 70-0373-104)
The rackmount installation option includes all the parts necessary to mount an EX1200 to the front
and rear of a standard test rack.
Required Tools
1) #2 Phillips screwdriver
2) 5/16" wrench or socket
Parts List
Item#
1
2
3
4
5
6
7
8
9
10
11
Assembly Procedure
1) Place the chassis on a protected work surface with its input connectors facing front.
2) Using a #2 Phillips screwdriver, install the rack ears (P/N: 41-0482-009) on the front of the
EX1200s using five (5) 6-32 x 3/8" flat head Phillips stainless steel screws (P/N: 37-0114-
025) for each rack ear. One ear should be installed on the left side of one chassis, while the
other ear is installed on the right side of the other chassis. Note that the "Optional Mounting
Locations" in Figure 2-7 allow the EX1200 to be installed in a rack either flush or recessed.
3) Next, attach a unit support bracket (P/N: 41-0482-011) to each EX1200 using two (2) 6-32 x
3/8" pan head Phillips SEMS screws (P/N: 37-0028-037) for each bracket (see Figure 2-7).
Note that the bracket should be installed on the same side as the rack ear installed previously.
4) Place the rear rack support brackets (P/N: 41-0482-011) on the inside of the unit support
brackets installed in step 3 and loosely secure them using two (2) 8-32 x 3/8" pan head
Phillips SEMS screws (P/N: 37-0073-037) and two (2) KEPS hex nuts (P/N: 37-0200-832)
per bracket. Loosely installing the hardware will allow the rear support bracket to adjust to the
proper length once installed in a rack.
5) Install the front mating bracket (P/N: 41-0493-006) on the right side of the EX1200 where the
rackmount/support brackets installed on the left using three (3) 6-32 x 3/8" flat head Phillips
stainless steel screws (P/N: 37-0114-025).
6) Install the rear mating bracket (P/N: 41-0493-007) on the right side of the EX1200 where the
front mating bracket was installed previously using two (2)4-40 x 0.187 pan head Phillips
Zinc screws (P/N: 37-0011-018).
7) Connect the two EX1200s by installing two (2) 4-40 x 3/8" flat head stainless steel Phillips
screws (P/N: 37-0100-037) through the right EX1200 capture the front mounting bracket.
Then, use two (2) 4-40 x 0.187 pan head Phillips Zinc screws (P/N: 37-0011-018) to connect
the rear mating bracket to the right EX1200.
8) Place the EX1200 in the desired rack slot and secure the front rack ears with hardware
provided with the rack. Once the front bracket are secured, slide the rear support brackets so
that they can be attached to the rack as well. After securing the rear support brackets, tighten
the screws and KEPS nuts installed in step 4.
42
Qty
Description
2
Bracket, Rack Ear, Single Half Rack, EX1262/02
1
Bracket, Front Mating, EX1262/02
1
Bracket, Rear Mating, EX1262/02
2
Bracket, Unit Support, EX1262/02
2
Bracket, Rear Rack Support, EX1262/02
Screw, 4-40 x 3/8", Flat Head Phillips, 82°, Stainless Steel
2
4
Screw, 4-40 x 0.187 Pan Head Phillips, Zinc
Screw, 6-32 x ¼", F/H Undercut Phillips, Zinc
13
Screw, 6-32 x 3/8" Pan Head Phillips, Sq Cone SEMS Zinc
2
Screw, 8-32 x 3/8" Pan Head Phillips, Sq Cone SEMS Zinc
6
4
Nut, Hex, KEPS, 8-32 Steel/Zinc
VTI P/N
41-0493-009
41-0493-006
41-0493-007
41-0482-010
41-0482-011
37-0100-037
37-0011-018
37-0114-025
37-0028-037
37-0073-037
37-0200-832
EX1200 Series Preparation for Use
