VTI Instruments Corp.
Rackmount Installation, Half Rack Width Option (P/N: 70-0373-103)
The rackmount installation option includes all the parts necessary to mount an EX1200 to the front
and rear of a standard test rack.
Required Tools
1) #2 Phillips screwdriver
2) 5/16" wrench or socket
Parts List
Item#
1
2
3
4
5
6
7
8
Assembly Procedure
1) Place the chassis on a protected work surface with its input connectors facing front.
2) Using a #2 Phillips screwdriver, install the rack ears (P/N: 41-0482-009 and 41-0493-011) on
the front of the EX1200 using five (5) 6-32 x 3/8" flat head Phillips stainless steel screws
(P/N: 37-0114-025) for each rack ear. Note that the "Optional Mounting Locations" in
Figure 2-6 allow the EX1200 to be installed in a rack either flush or recessed.
3) Next, attach the unit support brackets (P/N: 41-0482-010) to the EX1200 using two (2) 6-32 x
3/8" pan head Phillips SEMS screws (P/N: 37-0028-037) for each bracket (see Figure 2-6).
4) Place the rear rack support brackets (P/N: 41-0482-011) on the inside of the unit support
brackets installed in step 3 and loosely secure them using two (2) 8-32 x 3/8" pan head
Phillips SEMS screws (P/N: 37-0073-037) and two (2) KEPS hex nuts (P/N: 37-0200-832)
per bracket. Loosely installing the hardware will allow the rear support bracket to adjust to the
proper length once installed in a rack.
5) Place the EX1200 in the desired rack slot and secure the front rack ears with hardware
provided with the rack. Once the front bracket are secured, slide the rear support brackets so
that they can be attached to the rack as well. After securing the rear support brackets, tighten
the screws and KEPS nuts installed in step 4.
40
Qty
Description
1
Bracket, Rack Ear, Single Half Rack, EX1262/02
1
Bracket, Long Rack Ear, Single Half Rack, EX1262/02
2
Bracket, Unit Support, EX1202/62
2
Bracket, Rear Rack Support, EX1202/62
Screw, 6-32 x ¼", F/H Undercut Phillips, Zinc
10
Screw, 6-32 x 3/8" Pan Head Phillips, Sq Cone SEMS Zinc
2
Screw, 8-32 x 3/8" Pan Head Phillips, Sq Cone SEMS Zinc
6
4
Nut, Hex, KEPS, 8-32 Steel/Zinc
VTI P/N
41-0493-009
41-0493-011
41-0482-010
41-0482-011
37-0114-025
37-0028-037
37-0073-037
37-0200-832
EX1200 Series Preparation for Use
