Package Contents

Before continuing, verify that the DFA1163 package that you received is
complete. Your package should have all the items listed in the following
table.
Item Part Number
1 50311F0100X00 (H)Round Head Screw w/Spring+Flat Washer Long Fei:P3x6L P3x6 iso/SW6x0.5 NI
2 50311F0111X00 (H)Flat Head Screw Long Fei:F3x5ISO+Nylok Black
3 50311F0144X00 I Head Screw Long Fei:
4 50311F0162X00 (H)Round Head Screw GW/Washer Long Fei
5 50311F0181X00 (H)P Head Screw Long Fei
6 50311F0245X00 Flat Head Screw Long Fei
7 50311T0050X00 I Head Screw Long Fei
NXG50 NUT S.C.:GE4N2SN10800
8 50322C0028X00
(Must be used with DC JACK)
NXG50 Washer S.C.:GJ4W1SN10800
9 50333F0008X00
(Must be used with DC JACK)
10 50344C0112X00 Copper Post Long Fei:Copper Post 8x5xM3
11 5044440031X00 Rubber Foot Kang Yang:RF20-5-4P
12 50501A1295X00 (N)Chassis for DFA1163M VER:A CHYUAN-JYH
13 5050200114X00 Fan for vDNA1160 VER:A SUN TAI:AD204020MBPA08
14 5060200394X00 Thermal Pad for vDNA1160 VER:A E-LIN
15 5060600038X00 NICE3120 Diamter Hole Plugs 康揚:MHD-7
16 5061711373X00 (N)SFP+ 2x1 Cage Chant Sincere:902GHB1BCTA2N1A3
17 5061711600X00 (N)54V Power Cover for DFA1163M VER:A CHYUAN-JYH
18 5061711601X00 (N)Fan Bracket for DFA1163M VER:A CHYUAN-JYH
19 60110A0235X00 Pizza Box for AGX5000 Switch PCB VER:A YI GIA
20 60111A0457X00 Outside Carton for NPA-1610-M (B3) VER:A YI GI
21 6012200052X00 PE Zipper Bag #8 炎洲:印刷由任袋8號
22 6012200062X00 PE Bag for DNA730/840 PANADVANCE
