Chapter 4: BIOS Setup
Serial Port 1 Configuration
This section is used to configure serial port 1.
Aptio Setup Utility - Copyright (C) 2021 American Megatrends, Inc.
Advanced
Serial Port 1 Configuration
[Enabled]
Serial Port
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Version 2.19.1266. Copyright (C) 2021 American Megatrends, Inc.
Serial Port
Enables or disables the serial port.
Change Settings
Selects an optimal setting for the Super IO device.
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Enable or Disable
Serial Port (COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
CPU Temperature
Detects and displays the current CPU temperature.
System Temperature 1 and System Temperature 2
Detects and displays the current temperature of the system.
CN9 Fan Speed and CN10 Fan Speed
Detects and displays the fan speed of CN4 and CN5.
CPU VCORE to P12V
Detects and displays the output voltages.
32
Aptio Setup Utility - Copyright (C) 2021 American Megatrends, Inc.
Advanced
Pc Health Status
CPU temperature : +30 C
System temperature 1 : +27 C
System temperature 2 : +27 C
CN9 Fan Speed : 8633 RPM
CN10 Fan Speed : N/A
CPU VCORE : +1.088 V
: +1.200 V
PVDDR
: +3.286 V
P3V3
P5V : +5.140 V
P12V : +12.288 V
Version 2.19.1266. Copyright (C) 2021 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
