Package Contents Cont.

Before continuing, verify that the DFA1163 package that you received is
complete. Your package should have all the items listed in the following
table.
Item Part Number
23 6013301556X00 EPE for DFA1163 VER:A SENTENEL
24 6019900289X00 Paper Plate for NSK6301 4 IN 1 Pack VER:A YI GIA
25 6019900290X00 Paper Partition for NSK6301 4 IN 1 PACK VER:A YI GIA
26 6019900291X00 Carton Lining for NSK6301 4 IN 1 PACK VER:A YI GIA
27 6023309081X00 Cable EDI:232091081804-RS
28 7400090005X00 Power Adapter DELTA:DPS-90AB-3 D
29 CE01000338X00 C Eeprom Of I211(Intel) VER:0.6 Color:A
30 50311F0100X00 (H)Round Head Screw w/Spring+Flat Washer Long Fei:P3x6L P3x6 iso/SW6x0.5 NI
31 50311F0111X00 (H)Flat Head Screw Long Fei:F3x5ISO+Nylok Black
32 50311F0144X00 I Head Screw Long Fei:
33 50311F0162X00 (H)Round Head Screw GW/Washer Long Fei
34 50311F0181X00 (H)P Head Screw Long Fei
35 50311F0245X00 Flat Head Screw Long Fei
36 50311T0050X00 I Head Screw Long Fei
NXG50 Nut S.C.:GE4N2SN10800
37 50322C0028X00
(Must be used with DC JACK)
NXG50 Washer S.C.:GJ4W1SN10800
38 50333F0008X00
(Must be used with DC JACK)
39 50344C0112X00 Copper Post Long Fei:Copper Post 8x5xM3
40 5044440031X00 Rubber Foot Kang Yang:RF20-5-4P
41 50501A1295X00 (N)Chassis for DFA1163M VER:A CHYUAN-JYH
42 5050200114X00 Fan for vDNA1160 VER:A SUN TAI:AD204020MBPA08
43 5060200394X00 Thermal Pad for vDNA1160 VER:A E-LIN
44 5060600038X00 NICE3120 Diameter Hole Plugs 康揚:MHD-7
