Chapter 2: Jumpers and Connectors

Block Diagram

- DDR4 2400 DIMM Socket x2
- DDR4 ECC UDIMM/RDIMM
TPM 2.0
Header
Super IO
NCT6683D
Power Button
RJ45
Console
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
BIOS
eMMC 5.0
LPC
PCIe3 x1
12C
Intel I211
2x PCIe3 x1
PoE0
2x Intel I225
CPLD
Microsemi
PD69104
LED
Control
MGMT Port
2x 2.5GbE
with PoE+
USB 3.0 x3
Intel Atom
C3758R SoC PCIe3 x2
C3558R SoC
PCIe3 x4
PCIe3 x2 + 1x USB3.0+ 1x USB2.0
1x SFI
LAN 1 LAN 0
uSIM
1x SFI
2x 5GMII
MDC/MDIO
Marvell Marvell
88E1543 88E6191X
1xSFP+
1xRJ45 1xRJ45 1xSFP
8x 1GbE Switch
with PoE+
PoE+ Combo
18
USB 3.0 x3
M.2 3080 M Key
for WiFi
M.2 2280 M Key
mmWave Antenna Module
M.2 3042/3052 B Key
for 5G LTE
PoE2
PoE1
Microsemi
Microsemi
PD69104
PD69104
