Chapter 2: Jumpers and Connectors

LAN Connector

Connector type: SFP and 10G SFP+
Connector location: J3
0
1
Pin Signal
T1 GND
T2 TxFault1
T3 TxDisable1
T4 P10G_Sda1
T5 P10G_Scl1
T6 ModABS1_L
T7 1_RS0
T8 RxLOS1
T9 1_RS1
T10 GND
L1 GND
L2 TxFault2
L3 TxDisable2
L4 P10G_Sda2
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Signal
T20 GND
T19 1_SFP+_TD-
T18 1_SFP+_TD+
T17 GND
T16 3P3V_SFP1_T
T15 3P3V_SFP1_R
T14 GND
T13 1_SFP+_RD+
T12 1_SFP+_RD-
T11 GND
L20 GND
L19 2_SFP+_TD-
L18 2_SFP+_TD+
L17 GND
Pin Signal
L5 P10G_Scl2
L6 ModABS2_L
L7 2_RS0
L8 RxLOS2
L9 2_RS1
L10 GND
13
Pin Signal
L16 3P3V_SFP2_T
L15 3P3V_SFP2_R
L14 GND
L13 2_SFP+_RD+
L12 2_SFP+_RD-
L11 GND
