Specifications

Category
Memory
Flash Memory
Protocols Supported
Serial Interface
Data Formats
Data Rates
Flow Control
Management
Security
System Software
LEDs
Ethernet
Power Requirements
Operating Temperature
Storage Temperature
Physical Dimensions
Certifications
Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)
Description
8 MEG
2 MEG
ARP, DHCP, FTP, HTTP, ICMP, IP, POP3, PPP, SMTP, TCP, Telnet,
TFTP, and UDP
Standard DCE serial
Serial, binary, asynchronous
300; 1200; 2400; 4800; 9600; 19200; 38400; 57600; 115200; 230400 bps
RTS/CTS (hardware)
Serial; Telnet
Username and password authentication using local database
Flash ROM standard: downloadable from a TCP/IP host (TFTP) or
Xmodem via Serial
ACT (Activity) and STS (Status)
IEEE 802.3
With External Power (MTS2SA-T) Power Consumption
@ 9V DC: Typical 240mA
With RS-232 Power (MTS2SA-T-R) Power Consumption
@ 5V DC: Typical 95mA
@ 10V DC: Typical 50mA
@ 15V DC: Typical 35mA
@ 20V DC: Typical 28mA
@ 25V DC: Typical 24mA
32° to +120°F (0° to 50°C); humidity range 25-85% (non-condensing)
-40°C to +85°C
3.5" w x 2.1" h x 0.98" d; 3.4 oz.
8.8 cm x 5.3 cm x 6 cm; 96 g
Safety Certifications:
UL60950
cUL60950
EN60950
ACA TS001 / AS 3260
EMC Safety Approvals:
FCC Part 15 Class A
EN55022
EN55024
CE Marked
Chapter 1 – Product Description and Specifications
Maximum 250mA
Maximum 105mA
Maximum 60mA
Maximum 45mA
Maximum 38mA
Maximum 34mA
8
