11. Appendix
11.4. Content of Backup File
The backup file contains numerous settings and parameters saved from the device. When the file is uploaded
to a device, the following will be overwritten:
Audio / Video crosspoint settings
Mute state, Lock state, Crosspoint state
Autoselection (mode, port priority, delay)
Video port name, Audio port name, HDCP setting
Port name, HDCP mode, HDMI mode, Power +5V mode
Test pattern mode, clock source, and type
Audio port name, Audio output enabled, S/PDIF mode
Port name, Volume, Balance, Gain
RS-232 mode, Control protocol, Baud rate, Data bits, Stop bits, Parity
Port name and CI (Command Injection) port number
Port status (enable / disable), Code length, Repetition code, Enable modulation
Input port name, Output port name
CI status (enable / disable), CI port number
Saved IR codes, names
DHCP status (enable / disable)
Static IP address, Network mask, Gateway address
MAC filter allowlist, Port blocking settings
TCP client settings (/CTRL/TCP)
RS-232 recognizer settings
Control lock status, Device label, Dark mode state
User EDID data (U1-U14), Emulated EDIDs by ports
Crosspoint presets (1-4)
Event manager: settings of all Events (E1-E100)
Values of the variables
TPS / HDMI input ports
HDMI output ports
Analog audio ports
Local and TPS serial port
Local and TPS IR port
Network settings
Further settings
Applied firmware package: v1.6.0b19 | LDC software: v2.5.13b5
MMX4x2 series – User's Manual
11.6. Factory Default Settings
Parameter
O1 (HDMI out 1) - MMX4x2-HDMI
O1 (HDMI out 1) - MMX4x2-HT200
O2 (HDMI out 2) - for both models
O1 (HDMI out 1)
O1 (HDMI out 1)
O3 (Audio out)
TPS mode *
HDCP
Test pattern mode
Test pattern clock source
Test pattern
Autoselect feature
Autoselect mode
Signal type
HDCP mode
Power 5V mode
Emulated EDID on all four inputs
Analog audio input port settings
Volume
Balance
Gain
Analog audio output port settings
Volume
Balance
IP address
Subnet mask
Static gateway
DHCP
Setting/Value
Video crosspoint settings
I1 (HDMI in 1)
I1 (TPS in 1)
I2 (HDMI in 2)
Audio crosspoint settings
A1 (original HDMI embedded audio)
A2 (original HDMI embedded audio)
A3 (analog audio input)
Video input port settings
Auto
Enabled
Disabled
480p
Bar
Video output port settings
Disabled
Priority detect
Auto
Auto
Always on
Factory #47: Universal HDMI PCM
0.00 dB (100%)
0 (center)
0.00 dB
0.00 dB (100%)
0 (center)
Network settings
192.168.0.100
255.255.255.0
192.168.0.1
Disabled
