7. LW3 Programmers' Reference
7.15. HTTP Messaging
DIFFERENCE:
This feature and the commands below are available from firmware v1.6.0b19.
Http post and put messages can be sent from the Lightware device for more integration with third-party
devices. #http

ATTENTION! This feature means posting or putting HTTP messages from the Lightware device to another
device. Encrypted transmission (HTTPS) is not supported.
7.15.1. Setting the Target IP Address
Command and Response
SET·/CTRL/HTTP/C1.ServerIP=<IP_address>
ç
pw·/CTRL/HTTP/C1.ServerIP=<IP_address>
æ
Example
ç SET /CTRL/HTTP/C1.ServerIP=192.168.0.220
æ pw /CTRL/HTTP/C1.ServerIP=192.168.0.220
7.15.2. Setting the TCP Port
Command and Response
SET·/CTRL/HTTP/C1.ServerPort=<port_no>
ç
pw·/CTRL/HTTP/C1.ServerPort=<port_no>
æ
Example
ç SET /CTRL/HTTP/C1.ServerPort=80
æ pw /CTRL/HTTP/C1.ServerIP=80
7.15.3. Setting the Target Path
This property sets the path in the target device where the post/put message is to be sent.
Command and Response
SET·/CTRL/HTTP/C1.File=<path>
ç
pw·/CTRL/HTTP/C1.File=<path>
æ
Example
ç SET /CTRL/HTTP/C1.File=/putxml
æ pw /CTRL/HTTP/C1.File=/putxml
MMX4x2 series – User's Manual
7.15.4. Setting the Message Header
Command and Response
ç
æ
Example
ç SET /CTRL/HTTP/C1.Header=Host: 192.168.0.220\r\nContent-Type: text/xml\r\nAuthorization: Basic
æ pw /CTRL/HTTP/C1.Header=Host: 192.168.0.220\r\nContent-Type: text/xml\r\nAuthorization: Basic
7.15.5. Sending a Post Message
Command and Response
ç CALL·/CTRL/HTTP/C1:post(<body_text>)
æ mO·/CTRL/HTTP/C1:post
Example
ç CALL /CTRL/HTTP/C1:post(<Command><Message><Send><Text>LI1R_P</Text></Send></
æ mO /CTRL/HTTP/C1:post
7.15.6. Sending a Put Message
Command and Response
ç CALL·/CTRL/HTTP/C1:put(<body_text>)
æ mO·/CTRL/HTTP/C1:put
Example
ç CALL /CTRL/HTTP/C1:put(<Command><Message><Send><Text>LI1R_P</Text></Send></Message></
æ mO /CTRL/HTTP/C1:put
Applied firmware package: v1.6.0b19 | LDC software: v2.5.13b5
SET·/CTRL/HTTP/C1.Header=<header_text>
pw·/CTRL/HTTP/C1.Header=<header_text>
YWRtaW46TGlnaHR3YXJlMDE=
YWRtaW46TGlnaHR3YXJlMDE=
Message></Command>)
Command>)
