7. LW3 Programmers' Reference
Unlocking an Output Port
ç CALL·/MEDIA/VIDEO/XP:unlockDestination(
HDCP Setting (Input Port)
SET·/MEDIA/VIDEO/<in>.HdcpEnable=<hdcp_status>
ç
HDCP Setting (Output Port)
SET·/MEDIA/VIDEO/<out>.HdcpModeSetting=<hdcp_mode>
ç
Test Pattern Generator
Test Pattern Generator Mode Setting
SET·/MEDIA/VIDEO/<out>.TpgMode=<tpg_mode>
ç
The Clock Frequency of the Test Pattern
SET·/MEDIA/VIDEO/<out>.TpgClockSource=<tpg_clock>
ç
Test Pattern
SET·/MEDIA/VIDEO/<out>.TpgPattern=<pattern>
ç
HDMI Mode Settings (Output Port)
SET·/MEDIA/VIDEO/<out>.HdmiModeSetting=<hdmi_mode>
ç
Querying the Recent TPS Mode
ç GET·/REMOTE/<tps_port>.tpsMode
TPS Mode Settings
SET·/REMOTE/<tps_port>.tpsModeSetting=<tps_mode>
ç
Audio Port Settings from Firmware v1.2.0
Querying the Status of Source Port
ç GET·/MEDIA/AUDIO/XP.SourcePortStatus
Querying the Status of Destination Port
ç GET·/MEDIA/AUDIO/XP.DestinationPortStatus
Querying the Audio Crosspoint State
ç GET·/MEDIA/AUDIO/XP.DestinationConnectionList
Switching Audio Input
ç CALL·/MEDIA/AUDIO/XP:switch(<audio_in>:<audio_out>)
Querying the Audio Autoselect Settings
ç GET·/MEDIA/AUDIO/XP.DestinationPortAutoselect
Changing the Autoselect Mode
ç CALL·/MEDIA/AUDIO/XP:setDestinationPortAutoselect(<out>:<state><mode>)
Querying the Input Port Priority
ç GET·/MEDIA/AUDIO/XP.PortPriorityList
)
<out>
Applied firmware package: v1.6.0b19 | LDC software: v2.5.13b5
MMX4x2 series – User's Manual
Changing the Input Port Priority
ç CALL·/MEDIA/AUDIO/XP:setAutoselectionPriority
Muting an Audio Input
ç CALL·/MEDIA/AUDIO/XP:muteSource(<audio_in>)
Unmuting an Audio Input
ç CALL·/MEDIA/AUDIO/XP:unmuteSource(<audio_in>)
Locking an Input Port
ç CALL·/MEDIA/AUDIO/XP:lockSource(<audio_in>)
Unlocking an Input Port
ç CALL·/MEDIA/AUDIO/XP:unlockSource(<audio_in>)
Muting an Audio Output Port
ç CALL·/MEDIA/AUDIO/XP:muteDestination(<audio_out>)
Unmuting an Audio Output Port
ç CALL·/MEDIA/AUDIO/XP:unmuteDestination(<audio_out>)
Locking an Audio Output Port
ç CALL·/MEDIA/AUDIO/XP:lockDestination(<audio_out>)
Unlocking an Audio Output Port
ç CALL·/MEDIA/AUDIO/XP:unlockDestination(<audio_out>)
Analog Audio Input Gain Setting
SET·/MEDIA/AUDIO/A3.Gain=<level>
ç
Analog Audio Output Level Settings by Exact Values
Setting the Volume (dB)
SET·/MEDIA/AUDIO/O3.VolumedB=<level>
ç
Setting the Volume (Percent)
SET·/MEDIA/AUDIO/O3.VolumePercent=<percent>
ç
Setting the Balance
SET·/MEDIA/AUDIO/O3.Balance=<level>
ç
Analog Audio Output Level Settings by Steps
Setting the Volume (dB)
ç CALL·/MEDIA/AUDIO/O3:stepVolumedB(<step>)
Setting the Volume (Percentage)
ç CALL·/MEDIA/AUDIO/O3:stepVolumePercent(<step>)
134
(<in>(<out>):<prio>)
