7. LW3 Programmers' Reference
7.26. LW3 Commands - Quick Summary
System Commands
Querying the Product Name
ç GET·/.ProductName
Setting the Device Label
SET·/MANAGEMENT/UID/DeviceLabel=<custom_name>
ç
Resetting the Device
ç CALL·/SYS:reset()
Restoring the Factory Default Settings
ç CALL·/SYS:factoryDefaults()
Querying the Package Version
ç GET·/MANAGEMENT/UID.PackageVersion
Querying the CPU Firmware Version
ç GET·/SYS/MB.FirmwareVersion
Control Lock
SET·/MANAGEMENT/UI.ControlLock=<lock_status>
ç
Identifying the Device
ç CALL·/MANAGEMENT/UI:identifyMe()
Toggling the Dark Mode Setting
SET·/MANAGEMENT/UI/DARKMODE.DarkModeEnable=<mode_state>
ç
Setting the Delay of the Dark Mode Setting
SET·/MANAGEMENT/UI/DARKMODE.DarkModeDelay=<delay_time>
ç
Running a Macro
ç CALL·/CTRL/MACROS:run(<macro_name>)
Cleartext Login Protection
Setting the Login Password
ç CALL·/LOGIN:setPassword(<password>)
Logging Into the Device
ç CALL·/LOGIN:login(<password>)
Logging Out of the Device
ç CALL·/LOGIN:logout(<password>)
Enabling/Disabling the Cleartext Login Function
SET·/LOGIN:LoginEnable=<login_state>
ç
MMX4x2 series – User's Manual
Video Port Settings
Querying the Status of the Input Ports
ç GET·/MEDIA/VIDEO/XP.SourcePortStatus
Querying the Connected Input Port Number
ç GET·/MEDIA/VIDEO/<out>.ConnectedSource
Querying the Status of the Output Ports
ç GET·/MEDIA/VIDEO/XP.DestinationPortStatus
Querying the Video Crosspoint Setting
ç GET·/MEDIA/VIDEO/XP.DestinationConnectionList
Switching Video Input
ç CALL·/MEDIA/VIDEO/XP:switch(<in>:<out>)
Querying the Video Autoselect Settings
ç GET·/MEDIA/VIDEO/XP.DestinationPortAutoselect
Changing the Autoselect Mode
ç
Querying the Input Port Priority
ç GET·/MEDIA/VIDEO/XP.PortPriorityList
Changing the Input Port Priority
ç CALL·/MEDIA/VIDEO/XP:setAutoselectionPriority (<in>(<out>):<prio>)
Muting an Input Port
ç CALL·/MEDIA/VIDEO/XP:muteSource(
Unmuting an Input Port
ç CALL·/MEDIA/VIDEO/XP:unmuteSource(
Locking an Input Port
ç CALL·/MEDIA/VIDEO/XP:lockSource(
Unlocking an Input Port
ç CALL·/MEDIA/VIDEO/XP:unlockSource(
Muting an Output Port
ç CALL·/MEDIA/VIDEO/XP:muteDestination(
Unmuting an Output Port
ç CALL·/MEDIA/VIDEO/XP:unmuteDestination(
Locking an Output Port
ç CALL·/MEDIA/VIDEO/XP:lockDestination(
Applied firmware package: v1.6.0b19 | LDC software: v2.5.13b5
CALL·/MEDIA/VIDEO/XP:setDestinationPortAutoselect(<out>:<state><mode>)
)
<in>
)
<in>
)
<in>
<in> )
<out> )
<out>
<out> )
)
