8. Firmware Update
8.5. Command Line Interface (CLI)
DIFFERENCE:
The Command Line Interface is available from LDU2 v2.9.0b9.
The CLI of the LDU2 software is a simple tool for creating scriptable device updates without the need for
human interactions. It allows batch updating with the same features that are available in case of GUI usage.
8.5.1. How to Run
Running under Windows OS
®
The installer of LDU2 puts the following file into the installation folder:
LightwareDeviceUpdaterV2_CLI.cmd
CLI is available by this file, the exe is not suitable for that purpose. Open a command line window to execute
or test the features directly.
Step 1. Open an Explorer window where the cmd file is located, the default is:
c:\Program Files (x86)\Lightware\Lightware Device Updater V2\LightwareDeviceUpdaterV2_CLI.cmd.
Step 2. Click on the address line (highlighed with blue in the picture), type cmd.exe and press enter. The
command interpreter window of Windows is opened at the path of the LDU2 install folder.
Step 3. Now you can use the LightwareDeviceUpdaterV2_CLI.cmd file with the commands and options that
are described in the coming sections:
Running under Linux
The Command Line Interface under Linux Operating Systems can be run by the following:
LightwareDeviceUpdaterV2.sh.
Running an update:
bash LightwareDeviceUpdaterV2.sh update --ip 192.168.0.115 --package ~/Downloads/tps-
tx200_1.6.4b2.lfp2
The commands and options are the same under Windows
examples with LightwareDeviceUpdaterV2_CLI.cmd.
#new
and Linux, too. The following sections contain
®
Applied firmware package: v1.6.0b19 | LDC software: v2.5.13b5
MMX4x2 series – User's Manual
8.5.2. How to Use
Command Structure
The commands can be run over CLI in the following way:
LightwareDeviceUpdaterV2_CLI.cmd [command] [options]
[Command]: a certain command described in the coming sections; only one command can be run at a time
[Options]: mandatory and/or optional parameters of the command, if any. Optional parameters have a
default value, which can be found at each affected command. You only have to define the parameter if
you want to apply a different value. The order of the options is arbitrary.
Important Notes
CLI is case-sensitive (including commands, options and other parameters).
▪
There is no limit regarding the number of the devices to update. At most 20 devices are updated
▪
simoultaneously, when one of them is finished, the following (21st) will be started automatically.
If an update is failed, the IP address of the affected device(s) are listed at the end.
▪
8.6. CLI Commands

INFO: The commands and options described in the following sections are the same under Windows
Linux, too. The examples contain LightwareDeviceUpdaterV2_CLI.cmd.
About the Examples
▪ Sent command is in blue,
▪ If the response in practice is longer than listed in the example, this symbol can be seen: [...].
8.6.1. Help
The defined commands and options can be listed by the help command.
Command
LightwareDeviceUpdaterV2_CLI.cmd help
Example
C:\Program Files (x86)\Lightware\Lightware Device Updater V2>LightwareDeviceUpdaterV2_CLI.cmd help
C:\Program Files (x86)\Lightware\Lightware Device Updater V2>lib\jre\bin\java.exe -jar lib\ldu2.jar help
Command line usage:
Win: LightwareDeviceUpdaterV2_CLI.cmd [command] [options]
Linux: LightwareDeviceUpdaterV2.sh [command] [options]
Commands:

* help

* version
* update
* deviceInfo
* restore
* packageOptions
[...]
response is in grey.
145
and
®
