6. LW2 Programmers' Reference
6.8. LW2 Commands – Quick Summary
General LW2 Commands
Querying the Supported Commands
 {LCMD}
Querying the Product Type
 {i}
Querying the Device Label
 {LABEL}
Querying the Control Protocol
 {P_?}
Querying the Firmware Version of the CPU
 {F}
Viewing Firmware for All Controllers
 {FC}
Viewing Installed Board
 {IS}
Connection Test
 {PING}
Restarting the Device
 {RST}
Compile Time
 {CT}
Querying the Health Status
 {ST}
Querying the Serial Number
 {S}
Restoring the Factory Default Settings
 {FACTORY=ALL}
AV Port Settings
Switching an Input to the Outputs
 {<in>@<out>•<layer>}
Muting an Output
 {#<out>•<layer>}
MMX4x2 series – User's Manual
Unmuting an Output
 {+<out>•<layer>}
Locking an Output
 {#><out>•<layer>}
Unlocking an Output
 {+<<out>•<layer>}
Viewing the Connection State on the Output
 {VC•<layer>}
Viewing the Crosspoint Size
 {getsize•<layer>}
Setting the Video Autoselect Mode
 {AS_V<out>=<state>;<mode>}
Setting the Audio Autoselect Mode
 {AS_A<out>=<state>;<mode>}
Setting the Video Input Priorities
 {PRIO_V<out>=<in1_prio>;<in2_prio>;...;<inn_prio>}
Setting the Audio Input Priorities
 {PRIO_A<out>=<in1_prio>;<in2_prio>;...;<inn_prio>}
Network Configuration
Querying the Current IP Status
 {IP_STAT=?}
Setting the IP Address
 {IP_ADDRESS=<type>;<ip_address>}
Setting the Subnet Mask
 {IP_NETMASK=<subnet_mask>}
Setting the Gateway Address
 {IP_GATEWAY=<gateway_addr>}
Applying the Network Settings
 {ip_apply}
Enabling/disabling the Ethernet Port
 {ETH_ENABLE=<switch>}
Applied firmware package: v1.6.0b19 | LDC software: v2.5.13b5
