10.3. Content of the backup file

The backup file contains numerous settings and parameters saved from the device. When
the file is uploaded to a device, the followings will be overwritten:
RS-232 mode, Control protocol, Baud rate, Data bits, Stop bits, Parity
Port name and CI* port number
Enable/Disable on Local, and TPS Link lines
Audio mode, HDCP setting, Port name
Volume, Balance, Gain, Port name
Port names, TPS mode, PoE (enabled / disabled), Ethernet (Enable / Disable)
Audio mode (Embedded / AUX1-4), HDCP setting
RS-232 mode, Control protocol, Baud rate, Data bits, Stop bits, Parity, CI port number
IR input port status (enable / disable), code length and repetition code
IR input port – Command injection mode (On / Off) and CI port number
IR output status (enable / disable), IR output modulation (enable / disable)
IR output port – Command injection mode (On / Off) and CI port number
Power +5V mode, Audio mode, HDCP mode, HDMI mode, Port name
Test pattern mode, clock source, and type
Volume, Balance, Gain, Mute setting, Port name
Port names, TPS mode, PoE (enabled / disabled), Ethernet (Enable / Disable)
Test pattern mode, clock source, and type
HDCP mode, HDMI mode, Power +5V mode
RS-232 mode, Control protocol, Baud rate, Data bits, Stop bits, Parity, CI port number
IR input port status (enable / disable), code length and repetition code
IR input port – Command injection mode (On / Off) and CI port number
IR output status (enable / disable), IR output modulation (enable / disable)
IR output port – Command injection mode (On / Off) and CI port number
DHCP status (enable / disable)
LW2, LW3 and HTTP port numbers
Static IP address, Network mask, Gateway address
Emulated EDID list, User EDID data (U1-U12)
Event manager: All Events' settings (1-100)
All Presets' settings (1-6)
* CI: Command Injection
Page 114 / 119
Local serial port
Ethernet settings
HDMI input port
Analog audio input port
TPS input port
HDMI output port
Analog audio output port
TPS output port
Network settings
Further settings
Section 10. Appendix
