Quick Start — MGP 464, cont'd
Step 4
Attach an output device to the RGBHV/YUV
BNC connectors and/or to the DVI output
connector (shown below).
N Analog is not
available on this
DVI connector.
RGBHV
R G B
/R-Y /Y /B-Y
H V
/HV
R G B
/R-Y /Y /B-Y
H V
/HV
RGsB
BNC output connectors
Step 5
Plug the MGP 464, input devices, and output
devices into a grounded AC source, and power
on the input and output devices. The following
diagram shows an example of an MGP 464 DI
application.
Camera
DVD
Extron
MGP 464 DI
5
Four Window
4
6
R
S R-Y H/HV
UT 7
EO INP 3 G/Y
B VID R VID V
RG R-Y H/HV
Multi-Graphic Processor H/HV
B-Y B/C
2 G/Y 4-DV I-D
R VID V UT INP
R-Y H/HV
H/HV B/C
1 B-Y I-D
G/Y VID 3-DV
R R-Y V INP UT
H/HV H/HV
B/C
G/Y B-Y I-D
VID V UT 2-DV
H/HV INP
B-Y B/C
50/6 Hz 0 1-DV I-D
240 INP UT
100-
MAX .5A
PC PC
MGP 464 DI connection diagram
QS-2 MGP 464 • Quick Start
DVI-D OUTPUT
RGBS
R G B
/R-Y /Y /B-Y
H V
/HV
R G B
/R-Y /Y /B-Y
H V
/HV
HD YUV Component Video
Remote User and
Administration Control
Control System
TCP/IP
Network
LAN R
UT
TP
232 /422 OU
RS- , R-Y , B-Y B/
B/Y B-Y
RG G/Y
R/
R-Y V
H/ HV
OUT PUT
S DVI
UT 17 VID
EO INP Y D
VID 14 VID OUN
TU AL Y BAC KGR
VIR 11 VID 18 VID R-Y DVI
Y C
8 VID 15 VID R-Y
Y C 19 VID
VID 12 R-Y VID B-Y
Y C 16 VID
9 VID R-Y B-Y
C 13 VID
R-Y VID B-Y
C 10 VID
B-Y
VID
B-Y
Preview
Monitor
Projector
PC PC
Step 6
Use the LCD menu screens and Adjust knobs to
configure the MGP 464 and adjust the picture
controls.
(See the following section, "Setting Up the
MGP 464" and "Adjusting the Picture Controls,"
in the next section. See chapter 2, "Installation,"
for installation instructions, chapter 3,
"Operation," for front panel operation
information, chapter 4, "Software Configuration
and Control," for control via the RS-232/422
interface, and chapter 5, "HTML Configuration
and Control," for control via the MGP 464 Web
pages..
Setting Up the MGP 464
After you have installed and connected the
MGP 464, follow these steps to configure and
adjust the unit to get it ready for use.
Configuring the MGP
Press the Menu button to access the Main menu,
shown on the next page. Then, repeatedly press
the Menu button to cycle through the menus
to access the Input Configuration, Output
Configuration, and Advanced Configuration
menus to perform steps 1 through 4.
Step 1
Use the Input Configuration menu to configure
inputs 1 through 4.
N The virtual inputs (5 through 19) can
be configured only via the Windows-
based control software, SIS commands,
or the Web pages. For information on
configuring those inputs, see chapter 4,
"Software Configuration and Control,"
and chapter 5, "HTML Configuration
and Control."
Step 2
Use the Output Configuration menu to configure
the output signal type and the output rate for the
desired resolution.
Step 3
From the Advanced Configuration menu, Test
Pattern submenu, select the Alternating Pixels
(Alt. Pixels) test pattern. Adjust your display's
active pixels, total pixels, and pixel phase settings
for optimal picture quality.
