Software Configuration and Control, cont'd
Windows -based Control Software
®
The MGP 464 Windows-based control software program provides a convenient way
to configure the inputs, output, windows, and images in each window. It also lets
you save and recall input and window presets, and perform nearly all the other
functions that can be accomplished via the front panel controls, the SIS commands,
or the MGP 464 Web pages.
Using the software, you can do the following types of tasks to configure your MGP:
Input configuration — Specify a name; video signal type; size in pixels of the active
Output configuration — Set output resolution, refresh rate, sync polarity, and
Picture controls — Position and size the four windows and the images within the
Presets — Create, save, and recall window and input presets.
Window configuration — Set window priority; border color; text label colors, size,
Background capture — Capture the entire display on the output screen and save it

Installing the software

The MGP 464 configuration software is provided on a CD that is delivered with
your MGP 464 unit. To use the software, you must install the program on your PC.
Follow these steps:
1.
2.
4-36 MGP 464 • Software Configuration and Control
video area; horizontal/vertical start points of the total video display area; and
the windows 1, 2, 3, and 4 pixel sampling points (pixel phase) for each of the
19 inputs.
signal type (RGBHV, RGBS, RGsB, or YUV bi-level and tri-level); select a test
pattern; and enable/disable blue mode in order to set video color and tint
levels.
windows, zoom in or out on the images/windows, and make fine adjustments
to contrast, brightness, color, tint, and detail.
and location; and transition effects for each window of the display.
as a bitmap, to be recalled and used as a window background when needed.
Insert CD ROM Disk B into your CD drive. The disk should start
automatically. If it does not, open your Windows Explorer and double-click
LAUNCH.EXE on the CD drive to start it.
On the Software Products Disk B screen (shown on the next
page), click the Software button.
