Operation, cont'd

Input configuration submenu adjustments

The table below shows how to make the selections and adjustments that are
accessed through the Input Configuration submenus.
Input Configuration submenu
Video type
The following video signal types are
accepted:
RGB S-video
YUV-HD Composite video
YUVi DVI (MGP 464 DI only)
RGBcvS
Film mode
For low resolution inputs. The
video signal type for the input you
are configuring must be set to YUVi,
composite video, or S-video in order
to place the input in film mode.
Vertical start position
The distance in pixels from the
top edge of the input's total video
display area to the top edge of its
active area
Horizontal start position
The distance in pixels from the
left edge of the input's total video
display area to the left edge of its
active area
Pixel phase 1
The point at which pixels are
sampled for window 1. (The values
cannot be changed when the input
is DVI, YUVi, S-video, or composite
video.)
Pixel phase 2
The point at which pixels are
sampled for window 2. (The values
cannot be changed when the input
is DVI, YUVi, S-video, or composite
video.)
Pixel phase 3
The point at which pixels are
sampled for window 3. (The values
cannot be changed for DVI, YUVi,
S-video, or composite video inputs.)
3-10 MGP 464 • Operation
Horizontal Knob Adjustment
Select input #1, 2, 3, or 4.
Select input #1, 2, 3, or 4.
Shows the current film mode
status for the displayed input:
On, Off, or na (not applicable).
Select input #1, 2, 3, or 4.
Shows the current vertical start
point for the displayed input.
Select input #1, 2, 3, or 4.
Shows the current horizontal
start point for the displayed
input.
Select input #1, 2, 3, or 4 for
window 1.
Select input #1, 2, 3, or 4 for
window 2.
Select input #1, 2, 3, or 4 for
window 3.
Vertical Knob Adjustment
Select the desired video format
for the displayed input.
Default: RGB
Select On or Off to turn 3:2 or 2:2
pulldown (film mode) on and off
for the selected input.
Increase or decrease the distance
in pixels from the top edge of
the video display's total area to
the top edge of its active area.
Default is 128.
Increase or decrease the distance
in pixels from the left edge of
the video display's total area to
the left edge of its active area.
Default is 128.
Increase or decrease the
displayed value to move the pixel
sampling point for window 1 to
an optimal sampling point that
ensures output clarity. The range
of settings is 0-31; default is 16.
Increase or decrease the
displayed value to move the pixel
sampling point for window 2 to
an optimal sampling point that
ensures output clarity. The range
of settings is 0-31; default is 16.
Increase or decrease the
displayed value to move the pixel
sampling point for window 3 to
an optimal sampling point that
ensures output clarity. The range
of settings is 0-31; default is 16.
