Specifications, Part Numbers, and Accessories
Specifications
Number/signal type ..................... 4 VGA-UXGA DVI, RGBHV, RGBS, RGsB, RsGsBs, RGBcvS,
Inputs 1-4 ........................................ (4) x 5 female BNC and 4 optional DVI-D
Inputs 5-19 ...................................... 15 female BNC
Nominal level ................................ 1 Vp-p for Y of component video and S-video, and for composite video
Minimum/maximum levels ........ Analog: 0.0 V to 2.0 Vp-p with no offset
Impedance ..................................... 75 ohms
Horizontal frequency .................... 15 kHz to 100 kHz
Vertical frequency .......................... 50 Hz to 120 Hz
Resolution range ........................... 640x480 to 1920x1200*, 480p, 576p, 720p, 1080i, and 1080p
DC offset (max. allowable)........... 0.5 V
Video processing
Digital sampling ............................ 24 bit, 8 bits per color; 160 MHz standard
Colors .............................................. 16.78 million
Video output
Number/signal type ..................... 1 scaled RGBHV, RGBS, RGsB, HD YUV component video
Connectors .................................... 5 BNC female, 1 DVI-I female
Nominal level ................................ 1 Vp-p for Y of component video and S-video, and for composite video
Minimum/maximum levels ........ 0.0 V to 1.0 Vp-p
Impedance ..................................... 75 ohms
Vertical frequencies ....................... 50 Hz, 60 Hz, 72 Hz, 96 Hz, 100 Hz, 120 Hz
Scaled resolution ........................... 640x480
Return loss ..................................... -30 dB @ 5 MHz
DC offset ........................................ ±25 mV with input at 0 offset
Switching type .............................. Triple-Action
Sync
Input type ...................................... RGBHV, RGBS, RGsB, RsGsBs, RGBcvS, YUV (tri-level or bi-level on
Output type .................................... RGBHV, RGBS, RGsB, YUV (tri-level or bi-level on Y channel)
Standards ........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level ..................................... 0.0 V to 5.0 Vp-p
Output level ................................... 0.6 Vp-p for component video (tri-level sync)
Input impedance .......................... 510 ohms
Output impedance ....................... 75 ohms
Polarity............................................ Positive or negative (selectable)
A-2 MGP 464 • Specifications, Part Numbers, and Accessories
component video (interlaced or progressive), S-video, composite video
4 to 15 (configurable) component video (interlaced), S-video, or
composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
*Only the reduced blanking version of the 1920x1200 resolution is sampled
at full bit rate.
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
, 800x600
1,2,3,4,5,6 1,2,3,4,5,6
1024x1024 , 1280x768 , 1280x1024
1,2,3 1,2
1366x768 , 1400 x 1050 , 1600 x 1200
1,2 1,2
HDTV: 480p , 576p , 720p , 1080i
2 1 1,2
1 = at 50 Hz 2 = at 60 Hz 3
Y channel)
TTL: 5.0 Vp-p, unterminated for RGBHV, RGBS
, 852x480 , 1024x768
1,2,3,4,5 1,2,3,4
, 1360x765 , 1365x768
1,2 1,2
1,2
, and 1080p
1,2 1,2
= at 72 Hz 4 = at 96 Hz 5 = 100 Hz
, 1024x852 ,
1,2,3,4
, 1365x1024 ,
1,2 1,2
6 = 120 Hz
