Introduction

About This Manual

This manual discusses how to install, configure, and operate the Extron MGP 464
multi-graphic processor.
Throughout this manual, the terms "MGP," "multi-graphic processor," and
"processor" are used interchangeably to refer to the same product.
About the MGP 464 Multi-Graphic Processor
The MGP 464 is a four-window RGB and video signal processor that can display up
to four video sources on a single screen in picture-in-picture or picture-by-picture
format. The MGP accepts RGB, HDTV, component, S-video, and composite video
signals on four fully-configurable inputs and 15 virtual inputs; and has one scaled
output. The processor provides switching among inputs and has picture controls
and presets.
The MGP 464 DI is an MGP 464 with a DVI input card installed, providing four DVI
input connectors. Both versions can be controlled remotely via the RS-232/RS-422
interface using Special Instruction Set (SIS
control software, or via an Ethernet LAN using the MGP 464's embedded Web
pages, SIS commands, or the Windows-based control software.
Features
Four windows — Up to four windows can be shown on a single display
Inputs — The MGP 464 has four fully configurable video inputs, which accept RGB,
DVI background input — A DVI input is provided on both models as a means to
Virtual inputs — 15 virtual inputs can be configured through software to accept
Output — The MGP 464 has one scaled output, available on a set of five BNC
Picture controls — Picture controls allow you to adjust the size, position,
Window and input presets — Window presets save sizing, positioning, and
Window transition effects — Six types of window transition effects (22 different
Freeze control — Freeze control freezes (locks) a window to the current image.
3:2 pulldown detection for NTSC video and 2:2 film detection for PAL — These
1-2 MGP 464 • Introduction
simultaneously, allowing up to four video and computer sources to be viewed
at once.
HDTV, component, S-video, and composite video signals. The MGP 464 DI
has four DVI inputs in addition.
display live video from a DVI source as a background.
standard definition component video, S-video, and composite video.
connectors for RGB and a DVI-I connector for DVI.
brightness, contrast, color, tint, detail, and zoom for each window.
priority information. Input presets save input signal type information and
picture control settings.
effects altogether) seamlessly mute and unmute (close and open) the four
windows.
advanced film mode processing features help maximize image detail and
sharpness for video sources that originated from film.
When film is converted to NTSC video, the film frame rate has to be matched
to the video frame rate in a process called 3:2 pulldown. Jaggies and other
image artifacts can result if conventional deinterlacing techniques are used on
film-source video.
™ ) commands or the Windows-based
