Table of Contents, cont'd
Using the Background Page
Selecting a background color
Displaying a background image
Using a DVI input............................................................................................................... 5-23
Using a bitmap image ....................................................................................................... 5-23
Uploading an image .................................................................................................... 5-24
Selecting a background image ................................................................................... 5-24
Chapter Six • Special Applications
Application 1: Connecting the MGP 464 to a Matrix Switcher
Setting up the MGP to work with the switcher
Using the MGP and the matrix switcher after the MGP is synchronized to the
matrix switcher ............................................................................................................ 6-5
Minimizing synchronization problems when not using the Sync to Matrix
feature ......................................................................................................................... 6-5
Application 2: Connecting Multiple MGP 464s in Succession
(Daisy-chaining)
Setting up MGPs for daisy-chaining
Appendix A • Specifications, Part Numbers, and Accessories
Specifications
Part Numbers and Accessories
Included parts
Optional accessories
Appendix B • Firmware Update Guide
Determining the Firmware Version
Using the LCD display at power-on
Using a Web browser
Using the Windows-based configuration software
Downloading the firmware
Updating the Firmware
Updating using the Web pages
Updating using the Windows-based control software
Updating using the Firmware Loader
