Gigabit Ethernet Pin #
GBE0_CTREF A14
3.3.5. SATA
Signal Pin #
SATA0_TX+ A16
SATA0_TX- A17
SATA0_RX+ A19
SATA0_RX- A20
SATA1_TX+* B16
SATA1_TX-* B17
SATA1_RX+* B19
SATA1_RX-* B20
SATA2_TX+ A22
SATA2_TX- A23
SATA2_RX+ A25
SATA2_RX- A26
SATA3_TX+ B22
SATA3_TX- B23
SATA3_RX+ B25
SATA3_RX- B26
(S)ATA_ACT# A28
Note: SATA 3 port is supported by build option in place of PATA port.
Pinouts and Signal Descriptions
Description
Reference voltage for Carrier Board Ethernet channel 1
and 2 magnetics center tap. The reference voltage is
determined by the requirements of the Module PHY and
may be as low as 0V and as high as 3.3V. The reference
voltage output shall be current limited on the Module. In
the case in which the reference is shorted to ground, the
current shall be 250 mA or less.
Description
Serial ATA channel 0, Transmit Output differential
pair.
Serial ATA channel 0, Receive Input differential
pair.
Serial ATA channel 1, Transmit Output differential
pair.
Serial ATA channel 1, Receive Input differential
pair.
Serial ATA channel 2, Transmit Output differential
pair.
Serial ATA channel 2, Receive Input differential
pair.
Serial ATA channel 3, Transmit Output differential
pair.
Serial ATA channel 3, Receive Input differential
pair.
ATA (parallel and serial) or SAS activity indicator,
active low.
I/O PU/PD Comment
GND min
3.3V max
I/O PU/PD Comment
O SATA AC coupled on Module
I SATA AC coupled on Module
O SATA AC coupled on Module
I SATA AC coupled on Module
O SATA AC coupled on Module
I SATA AC coupled on Module
O SATA Supported by build
option*
AC coupled on Module
I SATA Supported by build
option*
AC coupled on Module
O 3.3V PU 10K
3.3V
