Interrupt Request (IRQ) Lines

PIC Mode
IRQ# Typical Intterupt Resource
0 Counter 0
1 Keyboard controller
2 Cascade interrupt from slave PIC
3 Serial Port 2 (COM2)
4 Serial Port 1 (COM1)
5 Parallel Port
6 Generic
7 Generic
8 Real-time clock
9 Generic
10 Generic
11 Generic
12 PS/2 Mouse
13 GSPI, UART, I2C, SDIO
14 Gpio
15 Gpio
Note (1): These IRQs can be used for PCI devices when onboard device is disabled.
APIC Mode
IRQ# Typical Intterupt Resource
0 Counter 0
1 Keyboard controller
2 Cascade interrupt from slave PIC
3 Serial Port 4 (COM4)
4 Serial Port 3 (COM3)
5 Serial Port 2 (COM2)
6 N/A
7 Serial Port 1 (COM1)
8 Real-time clock
9 N/A
10 N/A
11 N/A
12 PS/2 Mouse
13 Math Processor
14 Primary IDE controller
System Resources
Connected to Pin
N/A
IRQ1 via SERIRQ
N/A
IRQ3 via SERIRQ / PIRQ
IRQ4 via SERIRQ / PIRQ
IRQ5 via SERIRQ / PIRQ
IRQ6 via SERIRQ / PIRQ
IRQ7 via SERIRQ / PIRQ
N/A
N/A
IRQ10 via SERIRQ / PIRQ
IRQ11 via SERIRQ / PIRQ
IRQ12 via SERIRQ / PIRQ
N/A
PIRQ
PIRQ
Connected to Pin
N/A
IRQ1 via SERIRQ
N/A
IRQ3 via SERIRQ
IRQ4 via SERIRQ
IRQ5 via SERIRQ
N/A
IRQ7 via SERIRQ
N/A
N/A
N/A
N/A
IRQ12 via SERIRQ
N/A
IRQ14 via SERIRQ
Express-KL2
Available
No
No
No
Note (1)
Note (1)
Note (1)
No
Note (1)
No
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
Available
No
No
No
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
No
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
Note (1)
