Boot - ADLINK Technology Express-KL2 User Manual

7.4.

Boot

7.4.1. Boot Configuration
Feature
Boot Configuration
Setup Prompt Timeout
Bootup NumLock State
Quiet Boot
CSM Configuration
Fast Boot
New Boot Option Policy
Boot Option Priorities
7.4.1.1. CSM Configuration
Feature
CSM Support
CSM16 Module Version
GateA20 Active
Option ROM Messages
INT19 Trap Response
Boot Option filter
Option ROM execution
Network
Storage
BIOS Setup
Options
Info only
1
On
Disabled
Enabled
Submenu
Disabled
Enabled
Default
Place First
Place Last
Info only
Options
Enabled
Disable
Info only
Upon Request
Always
Force BIOS
Keep Current
Immediate
Postponed
UEFI and Legacy
Legacy only
UEFI only
Info only
Do not launch
Legacy only
UEFI only
Do not launch
UEFI only
Legacy only
Description
Enable/Disable the onboard SATA controllers.
Select SATA controller mode.
Enable/Disable the PATA port. In fact this enables or
disables the SATA channel on which the onboard
SATA to PATA converter is attached. When set to
enabled the system boot will be delayed for the time
specified in PATA Port Detection Timeout if no PATA
device is connected.
Auto: Scan for PATA device and enable per default.
Define the maximum time to wait for drive detection on
PATA port.
Enables or disables boot with initialization of a minimal
set of devices required to launch active boot option.
Has no effect for BBS boot options.
Description
This option controls if CSM will be launched.
UPON REQUEST - GA20 can be disabled using BIOS
services. ALWAYS - do not allow disabling GA20; this
option is useful when any RT code is executed above
1MB.
Set display mode for Option ROM.
BIOS reaction on INT19 trapping by Option ROM:
IMMEDIATE - execute the trap right away; POSTPONED
- execute the trap during legacy boot.
This option controls what devices system can to boot.
Controls the execution of UEFI and Legacy PXE OpROM.
Controls the execution of UEFI and Legacy Storage
OpROM.
