7.3.8. Super IO
Feature
Super IO Chip
W83627DHG Super IO Configuration
Serial Port 1 Configuration
Serial Port
Device Settings
Change Settings
Serial Port 2 Configuration
Serial Port
Device Settings
Change Settings
Device Mode
Parallel Port Configuration
Parallel Port
Change Setting
Device Mode
BIOS Setup
Options
Info only
Info only
Enabled
Disabled
IO=3F8h; IRQ=4
Auto
IO=3F8h; IRQ=4
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Enabled
Disabled
IO=2F8h; IRQ=4
Auto
IO=2F8h; IRQ=3
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Standard Serial Port Mode
IrDA Active pulse 1.6 uS
IrDA Active pulse 3/16 bit time
ASKIR Mode
Info only
Disable
Enable
Auto
IO=378h; IRQ5
IO=378h; IRQ5,6,7,9,10,11,12
IO=278h; IRQ5,6,7,9,10,11,12
IO=3BCh; IRQ5,6,7,9,10,11,12
STD Printer Mode
SPP Mode
EPP-1.9 and SPP Mode
EPP-1.7 and SPP Mode
ECP Mode
ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode
Description
Enable/Disable Serial Port (COM).
Fixed configuration of serial port.
Select an optimal setting for Super IO
device.
Enable/Disable Serial Port (COM).
Fixed configuration of serial port.
Select an optimal setting for Super IO
device.
Enable or Disable Parallel Port
(LPT/LPTE)
Select an optimal settings fpr super
IO Device
Change the Printer Port mode.
